1.Application:
It is mainly used for the torsion test of metal and nonmetal materials, as well as the torsion test for parts and components.
It is an essential instrument to measure torsion properties of materials for mechanics laboratories of aviation industry, construction industry, scientific research dept, universities and industrial enterprises etc.
2.Technical Parameter:
Model |
NDW -100 |
NDW -200 |
NDW -500 |
NDW -1000 |
NDW -2000 |
NDW -3000 |
NDW -5000 |
NDW -10000 |
Max Torque |
100N/m |
200N/m |
500N/m |
1000N/m |
2000N/m |
3000N/m |
5000N/m |
10000N/m |
Machine Level |
1 class or 0.5class |
|||||||
|
Torsion Angle Measurement Range |
2%-100%FS |
|||||||
Control Method |
Constant Torque And Constant Speed Rotation, Constant Speed Twist Angle Of The Closed Loop Control Mode |
|||||||
|
Torque Display Resolution |
1/20000 |
|||||||
|
The Accuracy Of Torque Values |
≤±1% |
|||||||
|
The Accuracy Of Torsion Angle Value |
Better Than±0.5% |
Torsion Angle Display Resolution |
1/20000 |
The Accuracy Of Angle Values |
≤±1% |
Angle Display Resolution |
0.01° |
Torsional Angular Rate Control Range |
0.05-800°/min |
|
Max. Reading Of Torsion Angel |
99999° |
|
Max. Distance Between Two Collets |
600mm |
Power |
220V±10%,50Hz |
3.Features:
This testing machine uses PC-controlled AC servo system and is loaded through the active clamping head driven by the AC servo motor and cycloidal pinwheel reduction motor.
The torque and torsion angle are measured with high-precision torque transducer and photoelectric encoder. Computer will dynamically display the test torsion curve, loading speed, peak value, and so on.
4. Software interface
Lifelong after-sales service & maintenance;
24 hours’ consult pre-sale on line or by Phone
Overseas training, installation is avaliable.
Jinan Hensgrand Instrument Co., Ltd. was established in 2001, is specialized in developing and manufacturing of testing equipments. The machiens are designed to test mechanical property of metal, non-metal and composite materials.
Our main products are Hydraulic Universal Test Machine, Electronic Universal Test Machine, Compression Testing Machine, Spring Testing Machine, Impact Testing Machine, Torsion Testing Machine, Hardness Tester, Testing Machine Accessories, etc.
Q:Are your company a trading one or a factory?
A:Factory + trade (integration),More than 20 years focusing on test instruments field,6 years exporting experience.
Q:After an order is placed, when to deliver?
A:Generally about 10-25days, If we have inventory, we can arrange shipment within 3 days.
Please be aware that our production lead times depend on specific items and item quantities.
Q:What about the warranty with after - sales services?
A:The testing machine is guaranteed for 16 months by HST,we can help you to repair
your problem controller freely,even it's not from our factory. After the warranty, the professional after-sale service team will provide perfect technical support and help guests solve problems encountered while using our product, handles guest
problems and complaints in a professional and timely.
Q:What about the product' services and quality?
A:Each instruments must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. We can arrange engineer to train the operation of equipment to customer’s company when you need.
products are widely recognized and trusted by users
NDW series Computerized Material Torsion Testing Machine
