Specifications
1.Vertical spring torsion testing machine2.Digital amplification, acquisition
3.LCD display
TNS-S/L series vertical spring torsion testing machine
Application:
TNS-S/L vertical manual spring torsion testing machine applies to twist spring, spring, elastic elements of rotor rolls and friction of the torsional horn, the test of torsional moment .It is the ideal testing equipment of industrial and mining enterprises, the technical supervision, inspection arbitration, scientific research institutes, universities and quality inspection unit and other departments
Features:
1.Torque, reverse angle for liquid crystal display.
2.Angle measurement using angular displacement sensor (photoelectric encoder) to the angular displacement of the torque sensor of automatic revision
3.The reverse testing machine also has peak keep, overload protection
4.Stiffness calculation, print the result,have the function such as data inquires, spin around to select, detection speed, when measuring the level on two specimens between disk torque.
5.Manual load,compact structure,simple operation,
6.Angle any settings, automatic acquisition torque values.
Technical parameters:
Model |
TNS-S/L vertical series |
Testing range |
50-2000N.mm |
Indicate range(N.mm) |
0-full load |
Load resolution (N.mm) |
0.001/0.01/0.1/1/10 |
Test corner range |
0-±9999.9 |
Torsion angle value of the Minimum reading |
0.1 |
Boom measurement range |
2-100%FS |
Sample height/length(mm) |
≤70/160 |
precision |
±0.5% |
Torque dish diam(mm) |
Φ100 |
Power supply |
AC220V 50Hz |
