Digital Spring Tensile Compression Testing Machine,/Manual Spring Tester

Name: Digital Spring Tensile Compression Testing Machine,/Manual Spring Tester
Brand: hensgrand
SKU: 126940283

US$ 999 - 1,699 MOQ: 1 Set

Key Specifications

Place of Origin:

China

Brand Name:

hensgrand

Model Number:

TLS-S

Jinan Hensgrand Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name hensgrand

Model Number TLS-S

Power Electronic

Usage Tensile Testing Machine

Specifications

1. Various spring tester
2. Digital display
3. Manaul operation
4. CE certificate

TLS-S manual spring tester

Application:

This machine is based on the country's spring and compressive tester standards

of technical requirement is made, professional design of automatic control and

data acquisition system, realized the data acquisition and control process full

digital adjustment. Can the compression spring, dish above precision extension

spring, spring, spring, leaf-spring tower, card of spring, spring, spring, composite, gas springs, die spring,

and special spring precision tension of the spring, stress, displacement, stiffness

and strength test and analysis.

Main specification:

Model	TLS-S
Max test froce(N)	50	100	200	500	1000	2000
Test froce accuracy(N)	0.005	0.01	0.02	0.05	0.1	0.2
Displacement accuracy (mm)	0.01	0.01	0.01	0.01	0.01	0.01
Tensile test max distance between two pressure plate(mm)	220	220	220	220	270	270
Compression test max distance between two pressure plate(mm)	220	220	220	220	270	270
Plate size(mm)	60	60	60	60	110	110
