Home > Products > Metallographic Equipment > MPZ-2 Automatic Metallographic Sample Grinding Polishing Machine
MPZ-2 Automatic Metallographic Sample Grinding Polishing Machine
- Qingdao China
- T/T Credit Card
You May Like
-
SQ-80 Diameter 80mm Metallographic Specimen Cutting Equipment
-
Iqiege-1 Manaul and Automatic Metallographic Specimen Cutting Machine
-
GTQ-5000B Metallographic Specimen Precision Cutting Machine
-
ZXQ-1 Automatic Metallographic Inlaying Equipment
-
HST-JSZ5 Binocular Stereomicroscope
-
HST-4XB Binocular Inverted Metallurgical Microscope
Product Details
| Place of Origin | Shandong, China | Brand Name | hensgrand | |
| Model Number | MPZ-2 | Power | Electronic | |
| Usage | Other, Grinding Polishing |
Product Description
MPZ-2 Automatic Metallographic Sample Grinding Polishing Machine
Main Application :
MPZ-2 Grinding and Polishing Machine suitable for metallographic specimen
pregrinding,grinding and polishing operation,is the necessary equppment to make metallographic
specimen.
Main Technical Parameters
Model | MPZ-2 |
Grinding Method | Automatic |
Grinding Wheel Diameter | 230 mm |
Speed | 100-1400 r/min, Stepless |
Test Block | 4 |
Air Pressure: | 2.3~8kg/cm2 |
Grinding Head Speed | 20-120 r/min, Stepless |
Sample size | MAXΦ45mm (Selectable, φ25, φ30, φ45 etc.) |
Pressurizing Force Adjustable Range | 0-6 Kg |
Rotation Angle of Grinding Head | adjustable |
Way of Pressure | separate pressurized |
Machine body | Plastic case, Corrosion resistant head, Antirust |
Interface | membrane switch, digital display, can set the grinding speed, timing, steering and tank cleaning function |
Display | 1. Speed 2. Time countdown 3. Air pressure |
Grinding Time | adjustable range 0-100 minutes (It can display the remaining time when grinding) |
Grinding Direction | forward or reverse direction |
Specimen Chuck | specimen fixture can be quickly replaced (quickly-disassembled function) |
Dimension (L*W*H) | 757×623×645mm |
Power Supply | AC220V |
Weight | 75kg |
MPZ-2 Automatic Metallographic Sample Grinding Polishing Machine
