MH320 portable hardness tester/copper hardness tester
- 300 Set / Sets per Month
- Qingdao China
- T/T Credit Card
Product Details
Place of Origin: | Shandong, China | Brand Name: | Hensgrand | Model Number: | MH320 |
Power: | Electronic | Usage: | Hardness Tester |
Product Description
MH320 portable leeb hardness test
Advantages:
1. Large screen (128×64 dot matrix LCD), showing all functions and parameters.
2. Test at any angle, even upside down.
3. Wide measuring range. It can measure the hardness of all metallic materials. Direct display of hardness scales HRB, HRC, HV, HB, HS, HL and three types of strength values immediately.
4. Seven impact devices are available for special application. Automatically identify the type of impact devices.
5. Large capacity memory could store 500 groups (Relative to average times32~1 ) information including single measured value, mean value, testing data, impact direction, impact times, material and hardness scale etc.
6. Upper and lower limit can be preset. It will alarm automatically when the result value exceeding the limit.Battery information indicates the rest capacity of the battery and the charge status.
7. User calibration function.
8. USB port with the PC humanity multi-functions data proceeding software.
9. Original imported high speed thermal printer supports the immediate printing function. It can save data permanently.
10. NI MH rechargeable battery as the power source. Charge circuit integrated inside the instrument. Continuous working period of no less than 150 hours (EL off and no printing).
11. Auto power off to save energy.
12. Excellent after-sale service system for high quality products. Easy to buy and comfortable to use.
Technical parameters:
Model | MH-320 |
Measuring range
| (170-960)HLD,(17.9-69.5)HRC,(19-683)HB,(80-1042)HV,(30.6-102.6)HS, (59.1-88)HRA, (13.5-101.7)HRB |
Measuring direction | 360° |
Hardness Scale | HL,HB,HRB,HRC,HRA,HV,HS |
Display | dot matrix LCD,128×64 dots |
Data memory | 500 groups max.(relative to impact times 1-26) |
Printing paper | width is (57.5±0.5)mm, diameter is 30mm |
Battery pack | 6V NI-MH |
Battery charger | 9V/500mA |
Continuous working period | about 150 hours(With backlight off, no printing) |
Communication interface | USB1.1 |
Outline dimensions | 212mm×80mm×32mm |
Operating conditions:
1.Environmental temperature: operating temperature-10 ~ + 50°C
2.Storage temperature: -30°C~ + 60°C
3.Relative humidity :≤90
4.The surrounding environment without strong vibration ,without a strong field, no corrosive medium and severe dust.
