astm monel 400 austenitic stainless steel pipe
Introduction
Monel 400 is a Nickel-Copper alloy with high strength and excellent corrosion resistance in a range of acidic and alkaline environments and especially suitable for reducing conditions. It also has good ductility and thermal conductivity.
Chemical Composition of Monel 400
The compositional range for Monel 400 is provided in the table below.
Element |
Content |
| Ni | 63 % min |
Cu |
28 - 34 % |
Fe |
2.5 % max |
Mn |
2 % max |
Typical Properties of Monel 400
Typical properties of Monel 400 are covered in the following table.
Property |
Metric |
Imperial |
Density |
8.8 g/cm3 |
0.318lb/in3 |
Melting point |
1350°C |
2460°F |
Co-Efficient of Expansion |
13.9µm/m.°C |
7.7x10-6 in/in.°F |
Modulus of rigidity |
65.3 kN/mm2 | 9471 ksi |
Modulus of elasticity |
105-120 kN/mm2 |
15230-17405 ksi |
Properties of Supplied Materials and Heat Treated Materials
Condition of Supply |
Heat Treatment (After Forming) |
|||
Annealed/Spring Temper |
Stress relieve at 300-320°C (570-610°F) for 1 hour and air cool. |
|||
Condition |
Approx Tensile Strength |
Approx Service Temp. |
||
Annealed |
400 - 600 N/mm2 |
58 - 87 ksi |
-200 to +230°C |
-330 to +445°F |
Spring Temper |
850 - 1050 N/mm2 |
123 - 152 ksi |
-200 to +230°C |
-330 to +445°F |
Relevant Standards
Monel 400 is covered by the following standard:
- BS 3075
- 3076 NA 13
- DTD 204B
- ASTM B164
Equivalent Materials
Equivalent materials to Monel 400 are:
- W.NR 2.4360
- W.NR 2.4361
- UNS N04400
- AWS 040
Applications of Monel 400
Monel 400 typically finds application in:
- Marine Engineering
- Chemical Processing
- Hydro-carbon Processing
- Heat Exchangers
- Valves
- Pumps
PackagingDetails: |
Products are well packed and clear labeled according to the regulations and customer's requests. |
| Delivery Detail: | 7-15days after receiving deposit |
1.Our Service For You
Pre-sale Service
1. Sample can be offered with sample charge and courier fee by buyer's side.
2. We have full stock,and can deliver within short time.Many styles for your choices.
3. OEM and ODM order are accepted, Any kind of logo printing or design are available.
4. Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you
5. All of our products are produce by our professional workman and we have our high-work-effect foreign trade team, you can totally believe our service.
6. We have 8 year experience of design, manufacture and sell lingerie, we cherish every order from our honor.
After you choose
1. We will count cheapest shipping cost and make invoice to you at once.
2. Check quality again, then send out to you at 1-2 working day after your payment,
3. Email you the tracking no, and help to chase the parcels until it arrive you.
After-sale choose
1. We are very glad that customer give us some suggestion for price and products.
2. If any question,please contact with us freely by E-mail or Telephone.
Name:Lucy Cui
Phone:021-67896311
