2016 Hot Selling Automatic Plastic Tube Sealing Machine

2016 Hot Selling Automatic Plastic Tube Sealing Machine photo-1
US$ 2,500 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
Automatic Grade:
Automatic
Payment & Shipping
Payment Methods:
Port of Shipment:
sz/hk
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
Automatic Grade Automatic
Driven Type Pneumatic
Voltage 220v/380v/50hz/60hz
Power 1500W
Place of Origin Guangdong, China
Brand Name JZMachinery
Model Number UT-M050A
Dimension(L*W*H) 605x550x890mm
Weight 100kg
Certification GMP
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

2016 hot selling Automatic plastic tube sealing machine





Product Description



1. Brief introduction:

Ultrasonic cosmetic tube sealing machine is suitable for toothpaste, cosmetics, medicines, food industrial supply, etc. With horizontal aluminum alloy structure, stainless steel package, environment friendly and sanitation. With independent platform,vertical /horizontal adjustable worktable, easy operation stable performance ,high efficiency.



2. Working principle:

Utilizing the energy produced by high speed vibration imposed on the tube and act on plastic tube in order heat the plastic tube rapidly and welding, under pneumatic mechanical pressure, forming the sealing the sealing  patterns of  to head mould foot mould while removal of excess material to reach good effect at last .



3. Main features:

-- Two dimensional adjustment of work piece platform, it is easy to operate.

-- Ultrasonic wave tube sealing machine adopts Taiwan cassette mechanism and circuit lines, using famous brand of ultrasonic parts.

-- Overload protection, phase separation protection, power-fail protection.

-- Large ultrasonic out put power to ensure the sealing quality of various specifications of tube.

-- Ultrasonic cosmetic tube sealing machine can seal soft tube and also can do  date printing and cutting.



Parameters:



Feature:





1. Manual loading the tube



2. Automatic ultrasonic sealing



3. Automaitc tube end trimming



4. Manual tube withdraw







 Specification:







Model UT-M050A  Ultrasonic tube sealing machine
Application Plastic tube, Composite tube
Tube Diameter 16-50mm
Tube length 50-200mm
Capacity  10-20pcs/min (max, accordingly to operator)
Mold 5pcs/set
Air pressure 0.5MPa
Dimension 605x550x890mm
Weight About 100kg







Machine:





Sample:
