Specifications
1.blank pcb boards2.UL,SGS,ROHS Certificate,E-test Service
3.OEM/ODM blank pcb boards
3.Competitive Price,fast delivery
UL/RoHS approved blank pcb boards
Welcome To Eastwin PCB board and PCBA Manufacturer
-----------------------------------------------------------------------------
Eastwin are able to offer one stop 1 to 12 Layer PCB fabrication,PCB manufacturing,component sourcing,
PCB Assembly,PCBA Function Test, design solution,Reverse engineering service
Our PCB board manufacture and SMT PCB Assembly service
* PCB board file with parts list provided by customers
* PCB board made, circuit board parts purchased by us
* PCB board with parts assembled
* Electronic testing circuit board or PCBA
* Fast delivery, anti-static package
* RoHS Directive-compliant, lead-free
Our PCB board Fabrication Capabilities:
Number of Layer |
1,2,4 or 6,upto 18 layer |
Order Quantity |
1 to 50,000 |
Board Shape |
Retangular,round,slots,cutouts,complex,irregular |
Board Type |
Rigid, Flexible, Rigid-flexible |
Board Material |
FR-4 glass epoxy, FR-4 high Tg, Rohs compliant,Aluminum,Rogers,etc. |
Board Cutting |
Shear,V-score,Tab-routed |
Board Thickness |
0.2-4.0mm, Flex 0.01-0.25mm |
Copper Weight |
1.0, 1.5, 2.0 oz |
Solder Mask |
Double-sided green LPI,Also support Red,White,Yellow,Blue,Black |
Silk Screen |
Double-sided or single-sided in white,yellow,black,or negative |
Silk Screen Min Line Width |
0.006'' or 0.15mm |
Max Board Dimensions |
20 inch*20inch or 500mm*500mm |
Min Trace/Gap |
0.10mm, or 4mils |
Min Drill Hole Diameter |
0.01'',0.25mm, or 10mils |
Surface Finish |
HASL,Nickle,Immersion Gold,Immersion Tin,Immersion Silver,OSP,etc. |
Board Thickness Tolerance |
±10% |
Copper Weight Tolerance |
± 0.25 oz |
Minimal Slot Width |
0.12'', 3.0mm, or 120mils |
V-Score Depth |
20-25% of board thickness |
Design File Formate |
Gerber RS-274,274D,Eagle and AutoCAD's DXF,DWG |
Our PCBA Board Fabrication Capabilities:
Quantity |
Prototype&Low Volume PCB Assembly,from 1 Board to 250,is specialty,or up to 1000 |
Type of Assembly |
SMT,Thru-hole |
Solder Type |
Water Soluble Solder Paste,Leaded and Lead-Free |
Components |
Passive Down to 0201 size BGA and VFBGA Leadless Chip Carriers/CSP Double-sided SMT Assembly Fine Pitch to 0.8mils BGA Repair and Reball Part Removal and Replacement |
Bare Board Size |
Smallest:0.25*0.25 inches Largest:20*20 inches |
File Formate |
Bill of Materials Gerber files Pick-N-Place file |
Types of Service |
Turn-key,partial turn-key or consignment |
Component packaging |
Cut Tape,Tube,Reels,Loose Parts |
Turn Time |
Same day service to 15 days service |
Testing |
Flying Probe Test,X-ray Inspection AOI Test |
Testing Procedures For PCB Board
---We perform multiple quality assurance procedures before shipping out any PCB board. These include:
· Visual Inspection
· Flying probe
· Bed of nails
· Impedance control
· Solder-ability detection
· Digital metallograghic microscope
· AOI (Automated Optical Inspection)
Detailed Terms for PCB board
Technical requirement for pcb assembly:
---- Professional Surface-mounting and Through-hole soldering Technology
---- Various sizes like 1206,0805,0603 components SMT technology
----ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
----PCB Assembly With UL,CE,FCC,Rohs Approval
----Nitrogen gas reflow soldering technology for SMT.
----High Standard SMT&Solder Assembly Line
---- High density interconnected board placement technology capacity.
Quote requirement for pcb assembly:
----Gerber file and Bom list
----Clear pics of pcba or pcba sample for us
----Test method for PCBA
Packaging:
Inner packing :Vacuum Package Outer packing:Standard Carton
---Finished boards are vacuum packed with bubble wraps and silica gel to prevent oxidization and damage during
transportation.All the PCB will be checked before shipping.
Lead Time For PCB Board and PCBA:
PCB Board:5-7 days
PCBA:20-25 days
Payment Terms:
TT&Paypal In Advance
View Of Our Factory
Our Superiority
1.High efficiency&Experience
We can provide one stop service.Established in 2004, with many years hard-working and constant innovation,we havegrown up into a professional PCB&PCBA manufacturer. We have our own independent research and developmentdepartment and sophisticated quality control system
--------------------------------------------------------------------------------
2.Quality
Our product are manufactured according to the UL/Rohs standards to insure quality assemblies from start to finish. Whetherit's a simple custom or not.Product or a complex turnkey production run, We will adhere to the highest quality standards.
--------------------------------------------------------------------------------
3.Protecting your interests
Protecting your Intellectual Property is job one! Our staff of trained professionals are all working under a strict confidentialitycontract and treat your important documentation as they would their own.
--------------------------------------------------------------------------------
4.Service
We can provide 24hours service for you. We pride ourselves on our ability to custom tailor programs around our customers'needs.We take time to listen to your unique business needs and then set out to surpass them
