Microwave oven pcba board with pcba oem service

Number of Layer

1,2,4 or 6,upto 18 layer

Order Quantity

1 to 50,000

Board Shape

Retangular,round,slots,cutouts,complex,irregular

Board Type

Rigid, Flexible, Rigid-flexible

Board Material

FR-4 glass epoxy, FR-4 high Tg, Rohs compliant,Aluminum,Rogers,etc.

Board Cutting

Shear,V-score,Tab-routed

Board Thickness

0.2-4.0mm, Flex 0.01-0.25mm

Copper Weight

1.0, 1.5, 2.0 oz

Solder Mask

Double-sided green LPI,Also support Red,White,Yellow,Blue,Black

Silk Screen

Double-sided or single-sided in white,yellow,black,or negative

Silk Screen Min Line Width

0.006'' or 0.15mm

Max Board Dimensions

20 inch*20inch or 500mm*500mm

Min Trace/Gap

0.10mm, or 4mils

Min Drill Hole Diameter

0.01'',0.25mm, or 10mils

Surface Finish

HASL,Nickle,Immersion Gold,Immersion Tin,Immersion Silver,OSP,etc.

Board Thickness Tolerance

±10%

Copper Weight Tolerance

± 0.25 oz

Minimal Slot Width

0.12'', 3.0mm, or 120mils

V-Score Depth

20-25% of board thickness

Design File Formate

Gerber RS-274,274D,Eagle and AutoCAD's DXF,DWG

Quantity

Prototype&Low Volume PCB Assembly,from 1 Board to 250,is specialty,or up to 1000

Type of Assembly

SMT,Thru-hole

Solder Type

Water Soluble Solder Paste,Leaded and Lead-Free

Components

Passive Down to 0201 size

BGA and VFBGA

Leadless Chip Carriers/CSP

Double-sided SMT Assembly

Fine Pitch to 0.8mils

BGA Repair and Reball

Part Removal and Replacement

Bare Board Size

Smallest:0.25*0.25 inches

Largest:20*20 inches

File Formate

Bill of Materials

Gerber files

Pick-N-Place file

Types of Service

Turn-key,partial turn-key or consignment

Component packaging

Cut Tape,Tube,Reels,Loose Parts

Turn Time

Same day service to 15 days service

Testing

Flying Probe Test,X-ray Inspection AOI Test

PCB assembly process

Drilling-----Exposure-----Plating-----Etaching&Stripping-----Punching-----Electrical Testing-----SMT-----WaveSoldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing
