75-200-600 Floor Deck Tile Roll Forming Machine

75-200-600 Floor Deck Tile Roll Forming Machine thumbnail-1
75-200-600 Floor Deck Tile Roll Forming Machine thumbnail-2
75-200-600 Floor Deck Tile Roll Forming Machine thumbnail-3
75-200-600 Floor Deck Tile Roll Forming Machine thumbnail-4
75-200-600 Floor Deck Tile Roll Forming Machine photo-1
75-200-600 Floor Deck Tile Roll Forming Machine photo-2
75-200-600 Floor Deck Tile Roll Forming Machine photo-3
75-200-600 Floor Deck Tile Roll Forming Machine photo-4
US$ 1,999 - 69,950 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Tile Forming Machine
Tile Type:
Colored Steel
Contact Supplier Request Quote Chat Now
Botou Huatong Corrugated Machinery Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Tile Forming Machine
Tile Type Colored Steel
Use Roof
Production Capacity about 10m/min
Place of Origin Hebei, China
Brand Name HUATONG
Model Number HT 75-200-600 roll forming machine
Power(W) 15kw
Voltage 380V/50Hz/3phase
Certification ISO 9001:2000
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.HT 75-200-600 roll forming machine
2.Step of roller:25steps
3.Dia of shaft:90mm
4.Guarantee:1 year

75-200-600 roll forming machine





1. Panel sizeof floor deck tile roll forming machine

75-200-600 floor deck tile roll forming machine



 Wave height  75mm
 Wave length  200mm
 Cover width  600MM
 Coil width  1250mm
 Thickness of formed steel   0.5-1.2mm



2. Steel floor deck tile roll forming machine main Parameters



Material of main frame 360 H steel
Thickness of middle plate 20mm
Dia of shaft 90mm
Chain 38.1mm
Motor power 15kw
Voltage 380V/50Hz/3phase
Roller 24 steps
Line speed about 10m/min
Accuracy of cutting +/- 2mm
PLC DELTA



3. Steel floor deck tile roll forming machine,  building bearing plate roll forming machine



75-200-600 floor deck tile roll forming machine75-200-600 floor deck tile roll forming machine75-200-600 floor deck tile roll forming machine75-200-600 floor deck tile roll forming machine







4. OEM / ODM ,Customers` Design ,Size,Color&Logo are accepted.



5. Competitive Price and Prompt Delivery



6. Markets:Middle East,  Europe, South Africa,Southeast Asia, North America.



7. Certification of HUATONG







 75-200-600 floor deck tile roll forming machine







Huatong roll forming machine scene

 75-200-600 floor deck tile roll forming machine





workshop about Huatong roll forming machine factory



75-200-600 floor deck tile roll forming machine









Sample room showing in Huatog roll forming machine factory



75-200-600 floor deck tile roll forming machine



Meeting room in Huatong roll forming machine factory



75-200-600 floor deck tile roll forming machine



Common useful of the sheet produced by  roll forming machine



75-200-600 floor deck tile roll forming machine

75-200-600 floor deck tile roll forming machine
