Help CenterDubai Outdoor LED TIME ,Date and Temp Board
Related Products
-
Dubai Outdoor LED TIME ,Date and Temp DisplayUS$ 450 - 550MOQ: 10 Sets -
Dubai LED Outdoor Clock Temmperature SignUS$ 450 - 550MOQ: 10 Sets
-
Canada 32inch Outdoor LED Large-screen Electronic ClockUS$ 1,180 - 1,300MOQ: 10 Sets
-
Mexico 32inch Outdoor LED TIME and Temp SignUS$ 1,180 - 1,300MOQ: 10 Sets
-
Canada Outdoor LED TIME and Temp PanelUS$ 1,180 - 1,300MOQ: 10 Sets
Production Description
Specifications
1. Life span 100,000 hours
2.CE,RoHs, and power supply with UL certification
3.Easy to install, plug -n- play
4.Two years warranty, or five years warranty regarding to led time, date and temp board's quotation
5.Good quality and fast after-service
Dubai Outdoor LED TIME ,Date and Temp Board
SUNPN-LED Time, Date and Temp Board Technical Function
1. Control system: SUNPN LED time, date and temp board control system, make time, date and temp change auto
2.High brightness available for outdoor led time, date and temp board
3. LED time, date and temp board dispaly format: 88:88,88+88,88+88% etc
4. LED time, date and temp board optional color: red, green, white, yellow, blue
5. LED time, date and temp board for customed design and control way
6. SUNPN can supply you finished or semi-finished LED time, date and temp board
7. One control card can control 8 pcs double-side led time, date and temp board
8. LED time, date and temp board approve ISO 9001-2008, CE, RoHs, power supply with UL etc certification
9.Control method: by RF remote, by PC, GPS, standard software or customer software
LED Time, Date and Temp Board Case
LED Time, Date and Temp Board Technical Parameters
| Optional Color | Red, Green,Yellow, Pure White, Blue |
| Digit height | 6",8",10",12",15",18",20",24",32", 45", 60" etc |
| Brightness control | auto dimming or handmade dimming |
| Brightness level | 8 level |
| View angle | 50° for standard |
| Service Access | Front or back service |
| Master/Slave | single/double side; master /slave available |
| Cabinet material | iron cabinet, aluminum cabinet |
| Waterproof rating | IP65 for outdoor product |
| Output Port | 485 driver signal/595 drive signal |
| Working voltage | 12V DC |
| Input Voltage | 110V-230V AC 50/60HZ |
| RF remote distance | ≤100m |
| Operating environment | -30°c to 75°c; 5% to 95% RH |
| Communication Interface | RS232/RS485/TCP/IP |
| Control Method | RF remote, PC, GPS |
| Installation method | Hang, mount on wall by hook or iron angle, or custom by customer |
| Standard Parts | RF remote, receiving antenna, light sensor, cooling fan, installation parts |
| Place of Origin | Longgang distric, Shenzhen city, P.R.China |
| Driver Pameters | |
| Drive port | One digit |
| Operating voltage | 12V DC |
| Max. current | 2A*8=16A |
| Drive Signal | RS485 |
LED Time, Date and Temp Board Drawing
LED Time, Date and Temp Board Control Way
LED Time, Date and Temp Board Module Size
About SUNPN Company
Built in 2004, specialize in led gas price sign, led gas price changer, led digital price sign, led numeric sign, led desiel price changer,led time and temp sign, led time, temp and date board,led countdown sign, led exchang rate board, led safety production board, led scoreboard sign, led parking sign etc. Use in gas station, super market, airport, train station, hotel etc.
All product are exported to USA, Germany, Spain, Italy, Australia, Saudi Arabia etc.
We expect helping you with what you want to buy !
We will be pleased to cooperate with you and do win 2 win business !
Please call me or email me ! Your inquiry will be answered in 12 hours !
Contact person:Annie Ou(skype:sunpn830)
