Specifications
Cup side sealing by ultrasonic.Bottom sealing by hot air station.
Make cups of different size by changing moulds.
HRX-P16 (12-16oz) Paper Cup Forming Machine with Ultrasonic Sealing on sale
Specification:
1. Paper cup bottom sealing by hot air station.
2. It is easy to make cups of different size by changing moulds.
3. Cup side sealing by ultrasonic.
4. Double PE coating paper cups for cold drink as well as hot drink.
5. Equipped with robotic arm and 3 pillar shafts each side, which let the machine run steadily.
6. With our unique original designed bottom knurling system, this ensures the low leaking ratio and high quality of paper cups.
7. Sucker import from Taiwan, which can reach 100 million times’ life span.
8. Design with special cover, our machine is very good for heat dissipation and ensure the longer life span.
| Technical data: | |
| #1 | Paper Cup Size RANGE: 12 ~~16 OZ |
| #2 | Speed: 38~~45 pcs/min |
| #3 | Paper cup top diameter: Min 45mm ~~Max 104mm |
| #4 | Paper cup bottom diameter: Min 35mm~~Max 75mm |
| #5 | Paper cup height: Min 110mm~~Max 140mm |
| #6 | Raw material: 180~~400gsm Single PE or Double PE coated paper |
| #7 | General power: 7kw |
| #8 | Electricity: 380V 3 phases or 220V 1 phase |
| #9 | Weight: 1800kg |
| #10 | Measurement: 2.8m×1.2m×1.8m |
One set of Mould including 68 pcs of parts in all as the following:
Picture show:
Bottom heating station 6mm iron frame
3 cam controls the cup clamp system 3 pillar shaft each side
Inner structure disassemble of the knurling set knurling set
Mechanical hand movable web iron cover
Packaging: plywood packing
Port: China any port
Delivery date: with 30days after recipt your payment
After-sales Service Provided: Engineers available to service machinery overseas
Guarantees:
We ensure that we can provide you with timely shipment, best possible service, responsible and customized packing, and guarantee that the goods arrive clean, neat and tidy, arrives to your satisfaction.
Welcome to our company. We hoping to cooperate with you and establish business relations worldwide.
Contact:
Name: Ann Doo
Tel: 86-010-62158015-808
Skype: hrx_cn05
Trade Manager: cn1501396606
Email: sales03*
Send Inquiry to This Supplier
