raymond grinder, raymond millcomplete grinding production system
Response within 2 hours
1 year warranty peri
raymond grinder LIMING
Raymond Mill is suitable for producing minerals powder, which is widely used
in the fields of metallurgy, building materials, chemical, and mining industry.Raymond
Grinder can be used to grinding the material that Moh's hardness degree is
below 7 , and humidity is in 6% non-flammable explosive minerals' processing.
The final product size is adjustable as required in the range of 100-325 meshes
( 0.125mm -0.044mm).
raymond grinder LIMING
Raymond mill is made up of the Mainframe, Separator, Pipeline System, Air Blower,
Jaw Crusher, Hopper Elevator, Electromagnetic Vibrating Feeder, and Electric
Control Motor and so on (for details see underlying graph of installation)
The main features of raymond grinder1.Three-dimensional structure , land-saving, easy to be a whole set2.The screen-passing rate can reach to 99%3.The transmission is steady and reliable;4.Centralized control for the electric system, convenient to operate
--
raymond grinder LIMING--
| Model | 3R2115 | 3R2615 | 3R2715 | 3R3016 | 4R3216 | ||
| Roller | Number | 3 | 3 | 3 | 3 | 4 | |
| Diameter (mm) | 210 | 260 | 270 | 300 | 320 | ||
| Height (mm) | 150 | 150 | 150 | 160 | 160 | ||
| Ring | Inside diameter (mm) | 630 | 780 | 830 | 880 | 970 | |
| Height (mm) | 150 | 150 | 150 | 160 | 160 | ||
| Maximum feed size (mm) | 15 | 15-20 | 15-20 | 15-20 | 20-25 | ||
| Output size (mm) | 0.044-0.165 | 0.044-0.165 | 0.044-0.165 | 0.044-0.165 | 0.044-0.165 | ||
| Power of main frame (kW) | 15 | 18.5 | 22 | 30 | 37 | ||
| Fineness of final product (mm) | 0.165 | capacity (t/h) | 1.2-1.8 | 1.8-2.5 | 2.3-2.8 | 2.6-3.2 | 3.2-4.5 |
| 0.075 | 0.6-1.2 | 1.2-1.8 | 1.8-2.3 | 1.9-2.6 | 2.4-3.1 | ||
| 0.044 | 0.6-1.0 | 0.8-1.2 | 0.9-1.7 | 1-1.9 | 1.8-2.5 | ||
Note: We hold the ringts to modify the design and specification of our products, any modification shall not be advised additionally.
Also,our company produce jaw crusher, impact crusher,hammer crusher, cone crusher
and grinder mills,ball mill,raymond grinder,sand making machines,belt conveyor
etc. welcome to enquiry!
