2016 35mm2 electric cable 35mm2 copper electrical power cable
Product Description
Characteristics for electrical cable :
1)Rated voltage U0/U : 0.6/1kV
2)Maximum conductor temperature is 90°C
3)Short circuit temperature (lasting for less than 5s):less than 250 °C
4)Ambient installation temperature shall be not lower than 0°C; minimum bending radius: for single-core cable,20(D+d)(mm), for multi-core cable, 15(D+d)(mm)(D=cable outside diameter, d= nominal diameter of main conductor).
5) Cable can be laid aerially, in trough, or underground
Product range of electrical cable
Type
Cu/XLPE/SWA/PVC, Al/XLPE/SWA/PVC
Voltage
0.6/1 kV
Cores
1C, 2C, 3C, 4C, 5C, 3C+1E,4C+1E, 3C+2E
Range of Nominal cross section
1.5 mm2 - 630 mm2
Application
XLPE insulated electrical cable applies to electrical power transmission and distribution lines with AC rated voltage U0/U up to and including 0.6/1 kV. For laying indoors, in tunnel, cable trench, well or direct in ground, able to bear external mechanical forces, and certain force
Standard
IEC 60502, BS 7870, GB/T12706
Company Introduction
Changfeng Wire & Cable Co., Ltd. was build in 1996, Domestic Sales Head Office is located in Beijing, International Trading Department is in Jinan, and the factory is located in Sha River Bridge Industrial Park, Hejian City, Hebei Province, covering an area of more than 178,000 square meters, the first phase construction area is 78,000 square meters more, registered capital 18 Million USD, project investment 81.8 Million USD. We professionally have engaged in Cable manufacturing for 18 years, our products cover: Power Cable, Mineral Insulated Flexible Fire Proof Cable, Alloy Cable, and ESP Cable for Oil Wells. We are approved by the State Administration for Industry and Commerce bareheaded administrative divisions, with the collection of cable research and development, production, sales in the integration of large international company.
Main Products
LV Power Cable & Control Cable / MV (35kV & below 35kV) Power Cable/ Armoured cable / Signal Cable / Flexible Cable/ Aerial Cable / Building Wire / Aluminum Alloy Cable / UL Wire
ESP Power Cable & Motor Lead Extension Cable / Fireproof cable / Mine Cable / Marine Cable / Railway Vehicle Cable / Rubber Cable etc.
