Help CenterYt High Speed Six Colors Flexo Printing Machine China
Related Products
-
Yt High Speed Six Colors Flexo Printing Machine ChinaUS$ 13,500 - 17,000MOQ: 1 Set -
Series Four Colors Flexo Printing Machine PriceUS$ 10,000 - 16,000MOQ: 1 Set
-
Plastic Bag Flexo Printing MachineUS$ 7,500 - 10,000MOQ: 1 Set
-
Flexo Printing Machine,MulticolorUS$ 125,000 - 200,000MOQ: 1 Set
-
YT Series Fours Color Flexo Paper Bag Printing MachineUS$ 9,500 - 15,000MOQ: 1 Set
Specifications
Yt High Speed Six Colors Flexo Printing Machine China1. Easy operation
2.Low power consumption
3. Fully Automatic,High effi
Yt High Speed Six Colors Flexo Printing Machine China
1. Features:
The flexo printing machine is suitable for printing such packing materials as polyethylene, polypropylene bag,
cellophane and roll paper,etc.
It is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag,
vest bag and clothes bag, etc.
2. Advantages:
1.simple operating, soft starting, accurate color register.
2.meter counter can set printing quantity, automatic shutdown, automatic stop-off material.
3.pneumatic landing plate cylinder, automatic mixing ink after lifting.
4.the knurled cylinder with ink, ink evenly.
5.Reliable drying system coordinated with high-speed operation, automatic shutdown circuit.
6.360 degrees continuous and adjustable longitudinal photo checking device.
7. frequency control, adapt to different printing speeds.
8. the roller seats and rewind shelves are loaded moving and stop buttons, easy to operate when the machine
is installed.
3.Technical Parameters:
Model of Machine |
YT-6600 |
YT-6800 |
YT-61000 |
Max.Width of Substrate |
600mm |
800mm |
1000mm |
Max.Printing Width |
560mm |
760mm |
960mm |
Range of printing Length |
191-914mm |
191-914mm |
191-914mm |
Max.Diameter of web |
450mm |
450mm |
450mm |
Printing Speed |
5-50m/min |
5-50m/min |
5-50m/min |
|
Plate Thickness(both side adhesive tape included) |
2.38mm |
2.38mm |
2.38mm |
Total Power |
13kw |
15kw |
18kw |
Weight of Machine |
3500kg |
4200kg |
5000kg |
Overall Dimensions |
3900*1660*2950mm |
3900*1860*2950mm |
3900*2060*2950mm |
4.Machine Pictures:
5.Sample Pictures:
6.Machine Package Pictures:
We are specializing in making paper bag making production line, including paper bag making machine,
flexo printing machine, rope making machine and handling making machine etc. We have both paper
bag making machine with roll feeder and sheet feeder.
1. Factory Show:
2. Certificates
3. Advantages&Service
1 We have several senior engineers service in many countries, all the year round with our after-sales office in multiple countries.
2 Machines with good quality in one year, life-long maintenance.
3 We have many machines can be monitored via the Internet, solve customer requirements in a timely manner.
4 We have several senior,continuous innovation and reform, in order to ensure the quality of mechanical stability.
5 Undertake various non-standard machinery, solve the customers' requirements.
4. Contact Information:
Contact Person:Helen Yu
Mobile:+86-13511480624 Tel:+86-577-256933332
Skype: paperbagmachine-NO.1
Add:Shangwang Industrial, Ruian city, Zhejiang province, China
Web:www.xiaohai-machin
