Home > Metallurgy, Mineral & Energy > Solar & Renewable Energy > Solar Controller > TRACER-1215 MPPT Tracer Solar Charger Controller Regulator

TRACER-1215 MPPT Tracer Solar Charger Controller Regulator

Name: TRACER-1215 MPPT Tracer Solar Charger Controller Regulator
Brand: linquan
SKU: 126573559
Availability: InStock

TRACER-1215 MPPT Tracer Solar Charger Controller Regulator thumbnail-1

TRACER-1215 MPPT Tracer Solar Charger Controller Regulator photo-1

US$ 103 - 115 MOQ: 5 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

linquan

Model Number:

TRACER-1215

Contact Supplier Request Quote Chat Now

Jinan Linquan Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO/TIANJIN

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name linquan

Model Number TRACER-1215

Application Solar System Controller

Rated Voltage Other, 12V/24V auto work

Maximum Current 10A

Specifications

TRACER1215 MPPT Tracer Solar Charger Controller Regulator
Advanced MPPT technology
lar input voltage150VDC
CE
MOQ1UNIT

TRACER1215 MPPT Tracer Solar Charger Controller Regulator

Technical Specifications

Description	Parameter
Norminal system voltage	12VDC or 24VDC
Rated battery current	10A
Battery voltage range	9 – 36V
Max. solar input voltage	TRACER-1206 60VDC TRACER-1210 100VDC TRACER-1215 150VDC
Max. PV input power	12V/120W 24V/240W
Self-consumption	≤16mA
RJ45 connection	8pin
Load surge protect	35A

Features of product:

1. 12/24V auto recognition, 10A/15A/20A rated charging current.
2. Advanced maximum power point tracking technology to optimize using the solar system.
3. Widely used, automatic recognize day/night.
4. Timer function with 1-15 hours option for street light
5. Two load outputs. Each load can be individually controlled, and enhance the flexibility of the system.
6. Sealed, Gel and Flooded battery option.
7. Adopting temperature compensation and correcting the charging and discharging parameters automatically, improving the battery lifetime.
8. Electronic protection: Over charging, over discharging, overload, short circuit, and reverse polarity of both solar module(s) and battery.
9. RJ45 interface with remote meter, convenient to check operating parameters of controllers.
The TRACER series controller is for off-grid solar system and control the charging and discharging of the battery.

The controller features a smart tracking algorithm inside that maximizes the energy from the solar PV module and charge the battery.

At the same time, the low voltage disconnect function (LVD) will prevent the battery damage from battery over discharging.
The TRACER controller charging process has been optimized for long battery life and improved system performance.

The comprehensive self-diagnostics and electronic protection functions can prevent damage from installation mistakes or system faults.

In addition, the TRACER controller has a RJ45 interface to allow communication with a meter for remote monitoring.
Although the TRACER controller is very simple to configure and use, please take your time to read the operator’s manual and become familiar with the controller.

This will help you make full use of all the functions and improve your solar PV system.

MPPT Solar Charge Controller Technology:
The TRACER utilizes Maximum Power Point Tracking technology to extract maximum power from the solar module.

The tracking algorithm is fully automatic and does not require user adjustment, TRACER technology will track the array maximum power point voltage (Vmp) as it varies with weather conditions, ensuring that maximum power is harvested from the array through the course of the day.
