EPHC-EC Solar Home System Controller Regulator
US$ 30 - 55
MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
linquan
Model Number:
EPHC-EC
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO/TIANJIN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
10A/15A/20A Dual Load Output Solar Controller RegulatorUS$ 25 - 50MOQ: 5 Pieces -
10A/15A/20A Solar Lighting Controller RegulatorUS$ 25 - 50MOQ: 5 Pieces
-
Waterproof Solar Street Lighting Controller IP67US$ 27 - 45MOQ: 5 Pieces
-
Dual Battery Solar Charger Controller Regulator for Caravan and BoatUS$ 57 - 110MOQ: 5 Pieces
-
20A Dual Battery Solar Charger Controller Regulator for Caravan and BoatUS$ 57 - 110MOQ: 5 Pieces
Place of Origin
Shandong, China
Brand Name
linquan
Model Number
EPHC-EC
Application
Solar System Controller
Rated Voltage
Other, 12V/24V auto work
Maximum Current
10A
Specifications
EPHC-EC Solar Home System Controller RegulatorCurrent: 10A
Voltage: 12/24V auto work & 12V
PWM Charge mode
3 LED indicators
EPHC-EC Solar Home System Controller Regulator
| EPHC-EC | ||||||
| SOLAR CONTROLLER FOR SOLAR HOME SYSTEMS | ||||||
| EPHC series is a reliable and economical solar controller. | ||||||
| It is ideal for small solar home system or rural electrification PV system. | ||||||
| Features | ||||||
| Microcontroller digital accuracy | ||||||
| PWM Charge mode | ||||||
| State of charge (SOC) | ||||||
| Temperature compensation | ||||||
| Automatic detection of the voltage | ||||||
| Electronic protection | ||||||
| Short circuit protection | ||||||
| Reverse polarity protection | ||||||
| Reverse current protection at night | ||||||
| Over charging or discharging protection | ||||||
| Over load protection | ||||||
| Display | ||||||
| 3 LED indicators | ||||||
| PV: Green -charging | ||||||
| Battery: Green-Yellow-Red | ||||||
| Load: Red -low voltage warning and disconnect | ||||||
| LED blinking shows mistakes | ||||||
| Technical specification | ||||||
| EPHC10-EC series: 12 VOLT or 12/24 VOLT auto work, 10 AMPS (for PV and load) | ||||||
| Equalization voltage: | 14.8 Volt | |||||
| Boost voltage: | 14.4 Volt | |||||
| Float voltage: | 13.6 Volt | |||||
| Low voltage disconnect (LVD) | 11.10 Volt | |||||
| Low voltages reconnect (LVR): | 13.1Volt | |||||
| Temperature compensation: | -30mv/Deg C/12V | |||||
| Self-consumption: | 6mA maximum | |||||
| Terminals: | for wire sizes to 2.5mm2 | |||||
| Temperature: | -35 to +55 Deg C | |||||
| Notes: It is for 12V system. Please X2 for 24V system. | ||||||
| WARRANTY: One year warranty period. | ||||||
