Mono Solar Panel

Mono Solar Panel thumbnail-1
Mono Solar Panel photo-1
US$ 1.6 - 1.78 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
LQTRADE
Model Number:
LQ35-M36,LQ40-M36,LQ45-M45
Contact Supplier Request Quote Chat Now
Jinan Linquan Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO TIANJIN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name LQTRADE
Model Number LQ35-M36,LQ40-M36,LQ45-M45
Material Monocrystalline Silicon
Size 800mm*437mm*28mm
Number of Cells 36
Max. Power 35W,40W,45W

Specifications

Mono Solar Panel ,
15W and 20W.
5 years warranty,
25 years 80% power,
MOQ: 5PCS,$1.6~$1.78/w.

Mono Solar Panel

35W,40W,45W



ELECTRICAL CHARACTERISTICS

CELL TYPE

125 X 62.5 MONO SOLAR CELL

ITEM

LQ45-36M

LQ40-36M

LQ35-36M

Maximum Power (Wp)

45 W

40 W

35 W

Maximum Power Voltage (Vm)

18.216 V

17.64 V

17.136 V

Maximum Power Current (Im)

2.47 A

2.272 A

2.135 A

Open circuit Voltage (Voc)

22.14V

21.67 V

21.31 V

Short circuit Current (Isc )

2.63 A

2.467 A

2.375 A

Number of cells

36

Maximum system voltage

750VDC

Temperature coefficients of Pm

-0.37%/ °C

Temperature coefficients of Voc

-0.34%/ °C

Temperature coefficients of Isc

0.09%/ °C

Nominal Operating Cell Temperature

48 °C

Output tolerance

+/-3%

Standard Test conditions

STC:AM 1.5,1000w/m,Module Temperature 25°C

MECHANICAL CHARACTERISTICS

Size of module A x B x C

800×437×28 mm

Weight per piece

4.5 Kg

ABSOLUTE MAXIMUM RATINGS

Operating Temperature

-40°C — +85°C

Storage Temperature

-40°C — +85°C
