Poly Solar Panel 70W 12V

Name: Poly Solar Panel 70W 12V
Brand: lqtrade
SKU: 126572541

US$ 2.5 - 3 MOQ: 1 Kilowatt

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

lqtrade

Model Number:

LQ70-40P

Jinan Linquan Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO TIANJIN

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name lqtrade

Model Number LQ70-40P

Material Polycrystalline Silicon

Size 771*665*30 mm

Number of Cells 40

Max. Power 70W

Specifications

Poly solar panel 70W 12V
Warranty: 5 years.
25 years for 80% power, 10 years for 90% power
Delivery time:5~10 days

Poly solar panel 70W 12V

Poly Solar Panel Electrical Characteristics 70W
Item No.	LQ70-40P
Peak Power(WP)	70W
Voltage at Pmax(VMP)	17.5 V
Current at Pmax(IMP)	4.0A
Open circuit voltage(VOC)	22.20 V
Short circuit current(ISC)	4.03 A
Weight(KG)	6.2 KG
Efficiency(%)	13.70%
Max system voltage	700VDC
Dimension	771×665×30mm
Cell type	156*156mm
Testing condition: Illumination 1000W/m2,Module temperature 25°C,AM=1.5
Temperation coefficients:
Noct:	48°C±2°C
Current temperature coefficient	0.06±0.01%/K
Voltage temperature coefficient	-(78±10)MV/K
Power temperature coefficient	-(0.5±0.05)%/K
Mechanical Characteristics:
Type of output terminal	Junction box
Cable	LAPP(4.0mm2)
Lengths	900mm
Connection	type lv
5 -year	Products workmanship warranty
90%	output power within 10 years
80%	output power within 25 years
Certification	IEC61215, IEC61730 & CE
Applications:
Grid tied/off grid power system	Electric fencers,land-based navigation aids
Private residences	Water pumping
Electronic product.	Rural electrification
Cathodic protection	Telecommunication-Road lights
Remote telemetry	Instrumentation systems, security sensor
Traffice signaling	Camping/ RV/ Caravans
