Specifications
machinery block's work
1.CE&ISO9001
2.suitable for medium-sized factory
3.save labor&power
4.after service
QTJ4-26D machinery block's work
A: Production capacity of QTJ4-26D machinery block's work
Size(LXWXH) mm |
Pcs/mould |
Pcs/hr |
Pcs/shift |
390x190x190 |
4 |
500 |
4000 |
390x140x190 |
6 |
720 |
5760 |
390x90x190 |
8 |
1000 |
8000 |
240x115x53 |
18 |
2400 |
19200 |
The type QTJ4-26D can produce all kinds of hollow blocks and solid bricks and paving bricks,
only by changing different moulds.
B: Technical parameters of QTJ4-26D machinery block's work
Main machine size |
2000x2000x2000mm |
|
Pallet size |
850x450mm |
Main machine power |
12.75kw |
|
Weight of machine |
3Ton |
Mixer |
1.2m pan mixer |
|
Belt conveyor |
6m |
Forming cycle |
26seconds |
|
Voltage |
380v/3phase |
C: QTJ4-26D machinery block's work other information:
1. Area: Workshop area: 80-100m2, all factory area 3000m2, the bigger, the better.
2. Workers : five or eight.
3. Ratio of raw material:cement 8%-10% sand 30%-40% stone:50%-60%,about cement :sand : stone is1:4:5.
4.hollow block weight:
(390*190*190) :17KG,(190*140*190):13.5KG,(390*90*190):10KG
5. raw material consumption per day:50-70T
6. water consumption per day:3%-5% of raw material Weight.
D.QTJ4-26D machinery block's work guarantee:
Our hollow block making machine is of one year guarantee,during the period we could supply spare parts if they are broken.
E.QTJ4-26D machinery block's work pressure:
Hollow blocks can reach 8-10Mpa,Solid bricks can reach 10-12Mpa,so they have a high pressure,can be used widely.
