Steam Pipe Insulation Material--perlite Molding Machine

Steam Pipe Insulation Material--perlite Molding Machine photo-1
Steam Pipe Insulation Material--perlite Molding Machine photo-2
Steam Pipe Insulation Material--perlite Molding Machine photo-3
Steam Pipe Insulation Material--perlite Molding Machine photo-4
Steam Pipe Insulation Material--perlite Molding Machine photo-5
Steam Pipe Insulation Material--perlite Molding Machine photo-6
US$ 37,800 - 165,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, pipe covering machine
Pipe Material:
Other, expanded perlite
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, pipe covering machine
Pipe Material Other, expanded perlite
Application Other, pipe cover energy saving
Production Capacity 6000pcs/8hour
Place of Origin Shandong, China
Brand Name Tianyuan
Model Number BWY-D
Voltage Request
Power(W) 12.5kw
Dimension(L*W*H) 3.5x2.2x2.8m
Weight 6.5T
Certification CE ISO9001
Warranty One Year
After-sales Service Provided Engineers available to service machinery overseas
Product Description

1- Advantage Features of expanded perlite pipes.

    1- long service life.

    2- high strength.

    3- high quality and inexpensive.

    4- excellent chemical stability.

    5- excellent physical stability.

    6- excellent tensile strength.

    7- low thermal conductivity.

    8- best fire proofing and water proofing, sound proof.



2- Images -Expanded perlite pipe covering Machine photo:

steam pipe insulation material--perlite molding machine

steam pipe insulation material--perlite molding machinesteam pipe insulation material--perlite molding machine

steam pipe insulation material--perlite molding machine

steam pipe insulation material--perlite molding machinesteam pipe insulation material--perlite molding machine

steam pipe insulation material--perlite molding machine

steam pipe insulation material--perlite molding machine



3- Expanded perlite pipe covers parameters.

        Density: 220-350kg/m3

      Thermal conductivity: 0.076w/m.k

      Service temperature: -190~ 650 C°

      Color : white, gray.

      Compress strength: 0.6Mpa.

      Breaking strength:  0.25.

      Hydrophobicity:  99.2%.

      Moisture content: 5.

     Common size: thickness:30~150mm.

                            Length 500mm.

                            Outside diameter: 27-1400mm.





Company Information

*Huarun Tianyuan Factory

1*  We are the professional manufacturer of AAC Block PlantConcrete Brick Block machine & Expanded Perlite Slab/pipe Molding Machine & EPS Insert Concrete Hllow Block Machine, & Fireproof door core making machine, with high technology research develop teams, more than 15years experience in this fields, cover 80000sqm and more than 400 staffs.

2*  Our products with CE/ISO certification had been sold to more than 106 countries, and well received high acceptance.

3*  We had successfully designed the Slope protection brick machines for South-to-North water diversion project, this is the biggest water diversion project in China Government.

 4*  We had successfully designed EPS(polystyrene) insert concrete hollow block machines. For chinese North-East building company.

 5*  We had successfully designed thermal insulation Expaned Perlite Slab molding machines for outside wall heat insulation. We are top leader in Chinese markets, share more than 95% markets.

 6*  We ensure our products quality and best after sales service.

 We will do the best with clients' advice and susgestion.

steam pipe insulation material--perlite molding machine

steam pipe insulation material--perlite molding machinesteam pipe insulation material--perlite molding machinesteam pipe insulation material--perlite molding machine





Certifications

1> Certification of ISO 9001. CE(MD+LVD)

2> We have inspections every year by National Quality Technical Supervise Department.

3> Our Quality Inspection Department make test of each machine before loading.



Our Services

7*24hours online service.

@:Designing ,technical support and project;

@Engineer available for overseas installation and adjustment;

@All necessary documents and drawings and videos for free;

@Warranty one year after delivery.

@ 24hours Online service for all life time.



FAQ

1: Keep the machine in dry environment.

2: Before the first production, please fill hydraulic oil into the tank, keep the oil level higher than 80/180degree. And pay more attention to the oil Pressure.

3: Please check the Sensor position before each shift, and tighten them again.

4: After each shift, please cleaning all the equipments, and lubricating each running parts.

5: Please cut off the Total Power when User maintaining the machine.

6: When need to change mold, please discharge or install them slowly and keep the Up mold foot safety.

7: If need technical help, please call 0086-539-3551999, 24hours online service.
