1* We are the professional AAC Block Plant& Concrete Brick machine & Expanded perlite plate molding machine & EPS insert concrete hollow block machine supplier for 18 years, with 268 high qualified staff, and 20 engineers, 30 assistant engineers.
2* Our products with CE/ISO certification had been sold to more than 65 countries, such as Russia, Sultan,Burma ,India, Brazil and so on.
And we already have abroad offices, such as Brazil, India, Vietnam, Sri Lanka.
3* We had successfully designed the Slope protection brick machines for South-to-North water diversion project, this is the biggest water diversion project in China.
4* We had successfully designed New type Multiple function EPS insert concrete hollow block machines. For chinese North-East building company, and we are at top leading position.
5* We had successfully designed thermal insulation expaned perlite board making machines for outside wall heat insulation. We are top leader in Chinese markets, share 96% markets.
6* We ensure our products are Brand – new and it were had pruduced by ISO QUALITY, and supply best after sales service.
eps insert hollow block making machine, eps insert block machine, eps insert hollow machine
QX-4000 automatic type.
A: Production capacity of QX-4000 as following:
Size(LXWXH) mm |
Pcs/mould |
Pcs/hr |
Pcs/8hr |
390x240x190 |
4 |
480 |
4000 |
B: Technical parameters of QX-4000:
Main machine size |
4000x2200x3000mm |
Pallet size |
900x700mm |
|
Main machine power |
31.7kw |
Weight |
13Ton |
|
Test pressure |
16Mpa/cm2 |
Mixer |
JS500 |
|
Vibration forece |
50kn |
Belt conveyor |
8m |
|
Forming cycle |
30seconds |
Voltage |
380v/3phase |
Packing:
Nude in container. Or in plastic bag per clients needs.
Shipping:
1: From mixer to stacker need one 40ft high container.
2: If need silo and batching machine too, it will need total 3x40ft high containers
24hours at service.
@:Designing ,technical support and project;
@Engineer available for overseas installation and adjustment;
@All necessary document and drawing and video for free;
1: Delivery : 25days after advanced payment.
2: Keep the machine in dry environment.
3: After each shift, please cleaning all the equipments, and lubricating each running parts.
