Home > Products > New Products > CDH-200-400 Two color printing Napkin Machine
CDH-200-400 Two color printing Napkin Machine
- 10 Set / Sets per Month
- Xiamen port
- T/T Credit Card
- Toilet Paper Cutter/Kitchen Towel Cutting Machine Price with High Performance
- High Capacity 3200mm A3 A4 Paper Writing Paper Recycling Machine, Office Paper Product Machinery for Sale
- Best Price 3200 Model Office Paper Copy Paper Manufacturing Line with Good Reputation
- Henan Toilet Tissue Paper Cutter/Cutting Machine with High Quality
- 1880mm Type Napkin Paper Making Machine Made in China
- Manufacturer Supply1575mm Napkin Paper/Tissue Paper Manufacturing Machine
Product Details
Condition: | New | Product Type: | Facial Tissue | Processing Type: | Paper Folding Machine |
Place of Origin: | Fujian, China | Brand Name: | Chuangda Machinery | Model Number: | CDH-200-400 |
Voltage: | 380V, 50HZ .3 phase | Power(W): | 4KW | Dimension(L*W*H): | 5200*800*1600mm |
Weight: | 1800kg | Certification: | CE | Warranty: | one year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
two color printingStable machine
Good quality.
competitive price
Functions and Features:
The machine is mainly used to produce middling and disposable tissue paper. According to different demand , it is able to produce different color tissue paper , and the embossing design and print design can be decide by the customer. it is especially apply in printing the patterns , brand , and etc . And it is made up of steep-less speed regulation technology , convey system , printing , embossing system , folding system , counting system , cutting system etc . It can be used with pneumatic working parts , pure and various colors printing system according to the consumers ' demand . It has the
feature of tight and rational structure , easy operation , stable operation, complete functions and beautiful outlooks.
- 1. Count automatically and output in order
- 2. Adopt screw turning knife to cut and vacuum absorption to fold
- 3. Adopt steep-less adjusting speed to unwind raw paper roll, which may fix different tension of paper.
- 4. Printing color is clear and fresh, set
- 5. Napkin width can be decided by customers in a certain range, convenient for client to make and sell different products according to market request.
Main Technical Parameter:
l Electric Source : 380V 50HZ
l Total Power : 2.75--4 KW
l Product open size (mm) : 200*200mm—400*400mm
l Product folded size (mm) : 100*100mm—200*200mm
l Production speed: 500-600pcs per min ( Without printing)
400-450pcs per min ( With printing)
l They Folding way: 1/4 and 1/8
l Raw material roll diameter: ≤1200
l Paper Layer :1 or 2 layers (If make 1 layer, the paper should be more than 23gsm)
l Vacuum air blower: 5.5KW
l Machine overall size : 4150 x 800 x 1600 ( L x W x H )
l Weight : 1.5--1.8 T
