Specifications
Advantages:
1. Low malfunction rate in first 5 years. Life span is over 15 years.
2. With safety light curtain. Guarantee the safety of workers without influencing the auto-running of machine.
3. Equip stainless-steel-blowing tube. To avoid blowing tube can not cooling down which result from the rusting block up the water pipe.
4. Equip thicker linear rolling guide with 65 mm guide rod for the mould station moving. The machine has longer life span than those with 45-50mm guide rod which was used by other factories.
5. Auto-lubrication control system is a creative design which can renew the lubrication oil. Pump out certain volume of lubrication oil to each point. Collecting the used oil for cleaning and environmental friendly, while lengthen the life span of machine.
6. Equip hydraulic oil accurately secondary filter systemwith detector and indicator. Ensure the hydraulic oil is clean and guarantee the long life span of hydraulic system.
7. Equip hydraulic oil accurately secondary filter systemwith detector and indicator. Ensure the hydraulic oil is clean and guarantee the long life span of hydraulic system.
8.Equip servo valve and high-precision electronic caliper for mould station moving, PQ closed-loop control. To make the action of mould station moving more stable and energy efficient
9. The construction of blowing tube carrier and mould station are more stable, which is able to resist the force from the blowing tube without hook.
10. Equip accumulation air compressor, water-oil-dust separating system to make the pneumatic system more stable and long life.
11. Equip large hard-tooth faced redactor for extruding, which ensure energy efficient and long life.
12. Thick, high quality chroming guide rod can ensure energy efficient and long life.
13. Fittings from digitalize producing ensure we can change it as long as it is the same one.
| Technical specification | ||
| MAX comntainer capacity | L | 30 |
| Screw Dimeter | mm | 85 |
| Screw L/D ratio | L/D | 24/1 |
| Extruder driving power | Kw | 30 |
| Number of heating zone | zone | 4 |
| Screw heating power | Kw | 8.4~9.6 |
| Die heating zone | zone | 3 |
| Power of die heating | Kw | 5~7 |
| Capacity | L | 3.5 |
| MAX die-pin diameter | mm | 350 |
| Oil pump drive power | Kw | 18.5 |
| Clamping force | KN | 200 |
| Platen distance | mm | 400~1000 |
| MAX mould size (WxH) | mm | 650x750 |
| Blowing pressure | Mpa | 1 |
| Using quantity of compreession air | m3/h | 0.8 |
| Using quantity of cooling watr | m3/h | 0.3 |
| Cooling water pressure | Mpa | 0.4 |
| Size of mashine(LxWxH) | m | 4.2x2.7x3.5 |
| Weight of machine | TON | 11 |
Thanks for your reading and intested in our products, If you have any other questions, Please feel free to contact us by following info,thanks!
Mr Vicky
Sales Manager
----------------------------------------------------------------------------------------
TaiZhou Union Plastic Mould Co.,ltd
ADD: No,502,3,unit ,37Building,Lily Community,west industrial,huangyan,taizhou,zhejiang,china post code:318020
TEL/FAX:0576-89166530
Mobile:+86-13736206058
Whatsapp: +86-15267207870
Wechat/QQ: 2798299958
Skype:vicky.zhou.123
Email: sales(at)
