3 Ton Forklift Truck With 4.5m Container Mast With Japanese Isuzu Engine

3 Ton Forklift Truck With 4.5m Container Mast With Japanese Isuzu Engine thumbnail-1
3 Ton Forklift Truck With 4.5m Container Mast With Japanese Isuzu Engine thumbnail-2
3 Ton Forklift Truck With 4.5m Container Mast With Japanese Isuzu Engine thumbnail-3
3 Ton Forklift Truck With 4.5m Container Mast With Japanese Isuzu Engine thumbnail-4
3 Ton Forklift Truck With 4.5m Container Mast With Japanese Isuzu Engine thumbnail-5
3 Ton Forklift Truck With 4.5m Container Mast With Japanese Isuzu Engine thumbnail-6
3 Ton Forklift Truck With 4.5m Container Mast With Japanese Isuzu Engine photo-1
3 Ton Forklift Truck With 4.5m Container Mast With Japanese Isuzu Engine photo-2
3 Ton Forklift Truck With 4.5m Container Mast With Japanese Isuzu Engine photo-3
3 Ton Forklift Truck With 4.5m Container Mast With Japanese Isuzu Engine photo-4
3 Ton Forklift Truck With 4.5m Container Mast With Japanese Isuzu Engine photo-5
3 Ton Forklift Truck With 4.5m Container Mast With Japanese Isuzu Engine photo-6
US$ 10,500 - 10,800 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
VLIFT
Contact Supplier Request Quote Chat Now
Shanghai Vlift Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Qingdao Ningbo port for forklift
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name VLIFT
Model Number CPCD30
Type Other, forklift
Power Souce Diesel Engine
Rated Loading Capacity 3000kg
Max. Lifting Height 5750mm
Min. Lifting Height 2140mm
Fork Length 1070mm
Fork Width 125mm
Overall Dimensions 2730*1225*2520mm
Certification CE ISO SGS
After-sales Service Provided Engineers available to service machinery overseas

3 Ton Forklift Truck with 4.5m Container Mast With Japanese Isuzu engine



CPCD30 Technology Specification
Manufacturer VLIFT
Model Power shift CPCD30
Load capacity kg 3000
Load center   mm 500
Power unit   Diesel
Operator type Driver/seat
Tire type Pneumatic
Wheel    Front/rear 2/2
Max. lifting height mm 4500
Free lift mm 850
Fork size               L*W*T mm 1070*125*45
Tilt range   Mast forward/backward deg 6/12
Overall length(without fork) mm 2705
Total width mm 1225
Mast height (fork lowering) mm 2125
Overall height fork raised With backrest mm 5750
Height to head guard mm 2140
Turning raduis(outs ide) mm 2445
Front face of fork to front axle mm 480
Min. right angle stacking aisle without load length&clearence                      mm 2925
Speed Max Travelling full/no load km/h 18/19.5
Lifting full/no load mm/s 450/500
Lowering full/no load mm/s 450/450
Max.drawbar pull Power shift T/M full/no load kg 1500/1000
Gradeability at 1.6km/h Power shift T/M full/no load % 18/20
Truck weight kg 4560
Weight  distribution Full  load
front/rear		 kg 6490/890
No  load
front/rear		 kg 1670/2700
Tires Number  front/rear 2/2
Model front axle   28x9-15-12PR
rear axle  6.50-10-10PR
Wheelbase mm 1700
Tread Front/rear mm 1000/970
Ground clearence At lowest point(mast) mm 120
Frame mm 135
Brake Service  brake Hydraulic-foot pedal
Parking brake  Mechanical-hand lever
Battery Voltage/capacity V/AH 12/80
Engine Model  Isuzu C240
Rated power kw/rpm 34.3/2500
Rated torque N.m 138/1800
Number of cylinders  4
Placement  L 2.369
Fuel tank capacity L 70
Transmission Speed forward/backward Power shift 1-1 power shift
Operating pressure Hydraulic system pressure kg/cm² 180



3 Ton Forklift Truck with 4.5m Container Mast With Japanese Isuzu engine

3 Ton Forklift Truck with 4.5m Container Mast With Japanese Isuzu engine

3 Ton Forklift Truck with 4.5m Container Mast With Japanese Isuzu engine



3 Ton Forklift Truck with 4.5m Container Mast With Japanese Isuzu engine



3 Ton Forklift Truck with 4.5m Container Mast With Japanese Isuzu engine



3 Ton Forklift Truck with 4.5m Container Mast With Japanese Isuzu engine





Certifications

3 Ton Forklift Truck with 4.5m Container Mast With Japanese Isuzu engine

FAQ

1. How long it will take to deliver the product after I pay for it?

Above price valid time is 25 days.

2. What is the payment term?

Our Payment: T/T, L/C, etc.

3. How long is the warranty period any forklift, pallet truck, stacker, scissor lift etc?

Our equipment quality warranty is 1 year or 2000 hours which comes first.

4. What kinds of engine do you have and any gurantee?

Chinese engine, Japanese ISUZU, Mitsubishi, YANMAR, Nissan K21, Nissan K25 engine as per your request. Absolutely high quality.

5. How many colors of forklift you can supply?

Sliver, Orange, Yellow, Red. As Per Your Request.

6,What is the forklift standard configuration and spare parts?

Wide vision mast,standard fork,standard seat,direction switch,backrest,reversing lights,reversing buzzer,back-up mirror,light switch,light armor rack,klaxon,two pieces of multi-way valve,electric control,rear combination lamp,overhead guard,rain cover,urable tyre,lasso-parking brake,lifting and tilt joystick,rate-limiting valve of lifting,draebar pin,lighting,adjustable steering wheel,lilt line self-lock valve,full hydraulic power steering,handle,tool box,combination instrument,hydraulic return filter,hydraulic oil suction filter,hydraulic vernier,switch,brake,turning indicator.
