New fuel 225W Polycrystalline solar panel
1.TUV/IEC/CE certified
2.High efficiency.safety and high reliablity
3.Best price
New fuel 225W Polycrystalline solar panel/model/module with lowest price
FEATURES
`Long Service Life
`High Efficiency Solar Cells
`Special Aluminum Frame Design
`High Transmission, Low Iron Tempered Glass
`Advanced Cell Encapsulation
APPLICATIONS
`Solar power stations
`Rural electrification, Small home power systems
`Power supply for traffic, security, gas industry
`12V and 24V battery charging system
`Other industrial and commercial applications
Model |
SNM-P225W-60 |
Nominal power (Pm) |
225 Watt |
Power allowance |
±3% |
Optimized working voltage (Vm) |
29.00V |
Optimized working current (Im) |
7.75A |
Open circuit voltage (Voc) |
36.30V |
Short circuit current (Isc) |
8.10A |
Module efficiency |
13.5% |
Withstanding voltage |
DC1000V |
Dimension of module (L) |
1640×992×50mm |
Net weight (Kg) |
19kg |
Packing ( pcsMcarton) |
2 |
Dimension of package (L) |
1532×920×150mm |
Volume (m3) |
0.21 |
Gross weight ( Kg/carton) |
40 |
Dimension of pallet |
1562×1080×1950mm |
Quantity in a 40’ container |
20carton/pallet×13 pallet =260carton (520pcs) |
Time returnable &replaceable |
5 years |
Power attenuation |
10 years the output is no less than 90% 25years the output is no less than 80% |
