Home > Metallurgy, Mineral & Energy > Solar & Renewable Energy > Solar Cell > 230W Mono Crystalline Solar Panel, PV Module, TUV, Iec, CE, Cec Certified,IEC,
230W Mono Crystalline Solar Panel, PV Module, TUV, Iec, CE, Cec Certified,IEC,
US$ 0.3 - 0.5
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
green tech
Model Number:
PV Solar Panel 200~220W
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
190W Mono Cystalline Solar Panel, Solar Module, TUV,CE,IEC,CEC CertificationUS$ 0.3 - 0.5MOQ: 10 Pieces -
195W Mono Solar PanelUS$ 0.5 - 0.8MOQ: 20 Pieces
-
240W Poly Crystalline Solar Panel, PV Module, for Solar Power Plant With TUV, IEC, CE, CEC CertifiedUS$ 0.5 - 0.8MOQ: 20 Pieces
-
New Fuel 225W Polycrystalline Solar Panel/model/module With Lowest Price Plant With TUV, IEC, CE, CEC CertifiedUS$ 0.5 - 0.8MOQ: 20 Pieces
-
Cheap Solar Panel China,Poly 120Wp-160WpUS$ 0.5 - 1.4MOQ: 20 Pieces
Place of Origin
Zhejiang, China
Brand Name
green tech
Model Number
PV Solar Panel 200~220W
Material
Polycrystalline Silicon
Number of Cells
128
Max. Power
255W-260W
230W Mono Solar Panel/Module
1.TUV/IEC/CE certified
2.water-proved
3 warranty :25 years
4.unique style
230W Mono Solar Panel/Module (SNM-M230(96))
PV Panel TUV/IEC/CE certified
FEATURES
`Long Service Life
`High Efficiency Solar Cells
`Special Aluminum Frame Design
`High Transmission, Low Iron Tempered Glass
`Advanced Cell Encapsulation
APPLICATIONS
`Solar power stations
`Rural electrification, Small home power systems
`Power supply for traffic, security, gas industry
`12V and 24V battery charging system
`Other industrial and commercial applications
| Module | Type (96 series) | |||||||||
| Encapsulation | Glass/EVA/Cells/EVA/TPT | |||||||||
| Parameters | SNM-M215 | SNM-M220 | SNM-M225 | SNM-M230 | SNM-M235 | SNM-M240 | SNM-M245 | SNM-M250 | SNM-M255 | |
| Max power | Pm(W) | 215W | 220W | 225W | 230W | 235W | 240W | 245W | 250W | 255W |
| Tolerance | +/-3% | |||||||||
| Open circuit voltage | Voc(V) | 57.3 | 58.0 | 58.0 | 58.6 | 58.6 | 59.2 | 59.2 | 59.8 | 59.8 |
| Short circuit current | Isc(A) | 4.94 | 5.0 | 5.07 | 5.15 | 5.23 | 5.32 | 5.45 | 5.51 | 5.62 |
| Max. power voltage | Vmp(V) | 47 | 47.5 | 47.5 | 48 | 48 | 48.5 | 48.5 | 49 | 49 |
| Max. power current | Imp(A) | 4.57 | 4.63 | 4.74 | 4.79 | 4.89 | 4.95 | 5.05 | 5.10 | 5.20 |
| Practical Module Efficiency | η c(%) | 12.6% | 12.9% | 13.2% | 13.5% | 13.8% | 14.1% | 14.4% | 14.7% | 15.0% |
| Dimensions | (L*W*H) | 1575× 1082× 50mm | ||||||||
| Net Weight | (kg) | 21.5 | ||||||||
| Max. system voltage | (V) | 1000V DC | ||||||||
| Operate Temp. Scope | -40/+85' | |||||||||
| Resistance | 227g steel ball fall down from 1m height and 120m/s wind | |||||||||
| Warranty | Pm is no less 90% in 10 years and no less 80% in 25 years | |||||||||
| STC | (Standard Test Condition: 1000W/m2, AM1.5, and 25' ) | |||||||||
