25MHz Dual Channels Usb Oscilloscope Second Hand From China

US$ 181.11 - 190 MOQ: 1 Set

Key Specifications

Place of Origin:

Guangdong, China

Model Number:

UTD2025CL

Shenzhen Starmeter Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Model Number UTD2025CL

Product Description

1,Dual analog channels width range 1mV/div~20V/div;

2,7 inches widescreen LCD displays;

3,Special Print Scree Feature;

4,Supports plug-and-play USB storage device. Communication with and remote control of computer through the USB device;

5,USB drive system software upgrade;

6,Storage of waveforms setups and interfaces waveforms and setups reproduction;

7,Automatic measurement of 28 waveform parameters;

8,Unique waveform recording and replay function;

9,Multilingual menu displays.

Specifications

Specification	UTD2025CL
Channels	2
Bandwidth	25MHz
Sample Rate	250Ms/s
Rise Time	≤14ns
Memory Depth	25kpts
Waveform Acquisition Rate	≥2000wfms/s
Vertical Sensitivity	1mV/div~20V/div
Timebase Range	10ns/div~50s/div
Storage	Setup,Wave,Bitmap
Trigger Modes	Edge, Pluse, Video, Alternate
Interface	USB OTG,Pass/Fail
General Characteristic
Power	100-240VAC, 40-440Hz
Display	7 Inches 64K Color TFT LCD, 400×240
Product Color	White and Gray
Product Net Weight	2.2 Kg
Product Size (W×H×D)	306mm ×147mm × 122mm
Standard Accessories	Probe×2 (1×,10× switchable),Power Cord, USB Cable, PC Software CD
Standard Individual Packing	Gift Box, English Manual
Standard Quantity Per Carton	2 PCs
Standard Carton Measurement (L×W×H)	450mm × 420mm × 280mm
Standard Carton Cross Weight	8.5 Kg
