Main Technicial Parameter: OEM used metal roof panel roll forming machine
Item |
Specification |
|
|
Material |
Type |
steel coil & galvanized coils |
Thickness |
0.4-0.6mm |
|
Yield strength |
235Mpa |
|
Roller material |
45#Chrome steel |
|
Forming speed |
About 15-20m/min |
|
Working speed |
2-3m/min |
|
Speed adjusting mode |
AC Frequency |
|
Roller drive |
Decelerating motor + Chain drive |
|
Cutting mode |
Hydraulic cutting |
|
Cutter material |
Cr12 mould steel |
|
Length measurement |
Encoder |
|
Control mode |
PLC |
|
Operating mode |
Button + Touch screen |
|
Main motor |
5.5KW |
|
Hydraulic Station motor |
5.5KW |
|
Components of Dongchang OEM used metal roof panel roll forming machine line,
No. |
Name |
Unit |
Qty |
1 |
Decoiler |
set |
1 |
2 |
Main machine for roll forming |
set |
1 |
3 |
Control system |
set |
1 |
4 |
Hydraulic system |
set |
1 |
5 |
Automatic cutting |
set |
1 |
6 |
Output table |
set |
1 |
Packaging Dongchang OEM used metal roof panel roll forming machine :
1.Tighten to container with steel wire rope and welded angel iron.
2.Main forming machine and unciler is naked (if you need we can also packed with water-proof plastic)
3.PLC control system and moter pump are packed with water-proof plastic coverage.
Delivery Detail:
5-7 days after receipt of buyer's deposit.
1,We will offer technical support for all the roll forming machines the whole life. 2 years free spare parts replacement and maintaince.
Our international technicians can be reach your workshop at the first time if your machines has problem.
2,If buyers visit our factory and check the machine, we will teach you how to install and use the machine, and also train your workers/technician face to face.
Without visiting,we will send you user manual and video to teach you to install and operate.
If buyer needs our technician to go to your local factory,please arrange board and lodging and other necessary things.
Working flow of Dongchang OEM used metal roof panel roll forming machine
Uncoiling→ Feeding material into machine →Roll forming →Measuring length→ Step formed
→ Auto cutting →Products receiving
1) Q: Are you manufacturer or trading company?
A: We are manufacturer and trading company .
2) Q: Do you provide installing and training overseas?
A: Overseas machine install and worker training services are optional.
3) Q: How is your after sales support?
A: We provide technical support on line as well as overseas services by skillful technicians.
4) Q: How does your factory do regarding quality control?
A: There is no tolerance regarding quality control. Quality control complies with ISO9001. Every machine has to past testing running before it's packed for shipment.
5) How can I trust you that machines pasted testing running before shipping?
A: 1) We record the testing video for your reference. Or,
2) We welcome you visit us and test machine by yourself in our factory.
6) Q: Do you sell only standard machines?
A: No. Most machines are made to order.
Our main production machines have follows:
1, |
Wall and roofing sheet roll forming machine / Metal tile forming machine |
2, |
C/Z purlin Auto size quick change forming machine |
3, |
Floor decking forming machine |
4, |
Highway guardrail roll forming machine |
5, |
Sandwich roll forming machine |
6, |
Stud and Track forming machine/light keel roll forming machine/ Roller Shutter Door Roll Forming Machine |
use
1 |
It is widely used in load bearing roof and buttree of large and medium-size industrial and civilian buildings |
2 |
Like factory ,workshop ,garage , warehouse, locomotive shed, hanger, exhibition building, cinema, theatre, stadium, garden etc |
3 |
They are widely used as the supporter of roof and wall in large-scale and mid-scale construction |
