Popular in Africa Market Coal/charcoal/mineral/sandstone Field Rotary Screening Equipment

Popular in Africa Market Coal/charcoal/mineral/sandstone Field Rotary Screening Equipment photo-1
US$ 300 - 1,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Circular, Screening equipment
Application:
Other, Ore;stone field;sandstone;coal/charcoal industry
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai;qingdao;dalian;ningbo;lianyungang;xiamen;guangzhou port etc.
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, Circular, Screening equipment
Application Other, Ore;stone field;sandstone;coal/charcoal industry
Place of Origin Henan, China
Brand Name Lan Tian
Model Number As you need
Voltage 220v 380v
Power(W) 3kw 4kw 5.5kw 7.5kw 11kw
Dimension(L*W*H) As the type you need
Weight As the type you need
Certification CE ISO 9001
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Popular in Africa market coal/charcoal/mineral/sandstone field rotary screening equipment

Product Description

  Popular in Africa market coal/charcoal/mineral/sandstone field rotary screening equipment

Introduction of rotary screening equipment:



Rotary screening equipment is used to screen stone,sandstone,coal ,charcoal ,mineral materials ,separate



big size and small size ,or one kind and another kind.and according to your raw material,production size and



mesh,our factory can make the most suitable rotary screening equipment  according to your requirement.





Structure of rotary screening equipment ,have several parts:



1.Motor



2.Accelerator



3.Roller device



4.Frame



5.Sealing cover



6.Input and output port





Widely application of rotary screening equipment:



Popular in Africa market coal/charcoal/mineral/sandstone field rotary screening equipment



1.In the stone field.for the size classification of stone,and separate the dirt and stone powder.



2.In the sandstone field,for the separate the sand and stone.



3.In the coal /charcoal industry,for the separate block and powder of coal /charcoal;washing coal



(part of coal washing machine).



4.In the chemical industry,mineral processing industry.for the size classification of blocks and powder.



Working principle of rotary screening equipment:



Popular in Africa market coal/charcoal/mineral/sandstone field rotary screening equipment



Working principle of rotary screening equipment is very simple, good understanding .Motor through coupling



connected together with accelerator and roller device,drive roller device to rotate around its axis.when



materials enter into the roller device,due to the tilting and rotation of roller device,the materials on the



screen is turned on and rolling.Qualified materials discharged by the screen of roller outer circle.Unqualified



materials discharged by the end of roller.Because the material keep on turning and rolling  inside the roller



so that the material stuck in the sieve can be ejected, can prevent clogging.





Advantage of rotary screening equipment :



1.Small power ,Low energy consumption.



2.Tube with self cleaning device, the mesh is not easy to be blocked



3.Small occupied space,Investment cost reduction.



4.Factory direct sale .Stable and reliable operation.



5.High screening efficiency,big output.



6.Easy to install, maintain, and operate.



7.Feeding mode:Artificial and mechanical drive.







  Popular in Africa market coal/charcoal/mineral/sandstone field rotary screening equipment



  Technical parameter of rotary screening equipment :


Model

Specifications

(m)

Dip

 angle

Speed

(r/min)

Screen size

(mm)

Max feeding size

(mm)



Capacity(m3/h)



Motor power

(kw)

Mesh size

(2mm)

Mesh size

(20mm)

GTS820

Φ0.8X2

32

2-20

Mesh sizeX2.5

7

30

3

GTS830

Φ0.8X3

32

2-20

Mesh sizeX2.5

8

50

3

GTS1030

Φ1X3

25

2-20

Mesh sizeX2.5

10

60

4

GTS1040

Φ1X4

25

2-20

Mesh sizeX2.5

11

80

4

GTS1230

Φ1.2X3

20

2-20

Mesh sizeX2.5

12

100

5.5

GTS1240

Φ1.2X4

20

2-20

Mesh sizeX2.5

14

120

5.5

GTS1250

Φ1.2X5

20

2-20

Mesh sizeX2.5

15

140

5.5

GTS1530

Φ1.5X3

17

2-20

Mesh sizeX2.5

16

120

5.5

GTS1540

Φ1.5X4

17

2-20

Mesh sizeX2.5

18

150

7.5

GTS1550

Φ1.5X5

17

2-20

Mesh sizeX2.5

20

180

11

GTS1560

Φ1.5X6

17

2-20

Mesh sizeX2.5

22

200

11





Company Information

Popular in Africa market coal/charcoal/mineral/sandstone field rotary screening equipment



Our Services

Our service of rotary screening equipment:



1. Pre-sales service:



    1). sales person, project manager, technology engineer, accountant staff.



    2). professional responding team: would be very fast and exactly to send you offer.



    3). choose suitable machines and make producing plan according to the raw materials, final shapes and



output capacity.



    4). offer reasonable price to meet your budget.



    5). invite customers to our factory, let you know how the machine work, and compare the quality with other



suppliers.



    6). producing super and solid quality of machines.



    7). arrange shipping and fast delivery.



    8). standard export package or as your requirements.



2. After-sales service:



    1). assistance to build factory.



    2). repairing and maintain if any problems occur in the warranty.



    3). help for installation or clerk training, if necessary, dispatch technicians to your country to install the



machines.





Contact us



If you are interested in our rotary screening equipment ,please contact me freely!



Welcome your inquiry!
