Top quality wide application mineral/coal /charcoal /ore separator
Introduction of ore separator:
Ore separator is used for sieving stone,sandstone,coal ,charcoal ,mineral materials ,separate big size and
small size ,or one kind and another kind.and according to your raw material,production size and mesh,our
factory can make the most suitable ore separator according to your requirement.
Structure of ore separator:
1.Motor
2.Accelerator
3.Roller device
4.Frame
5.Sealing cover
6.Input and output port
Widely application of separator:
1.In the stone field.for the size classification of stone,and separate the dirt and stone powder.
2.In the sandstone field,for the separate the sand and stone.
3.In the coal /charcoal industry,for the separate block and powder of coal /charcoal;washing coal
(part of coal washing machine).
4.In the chemical industry,mineral processing industry.for the size classification of blocks and powder.
Working principle of ore separator:
Working principle of ore separator is very simple, good understanding .Motor through coupling connected
together with accelerator and roller device,drive roller device to rotate around its axis.when materials enter
into the roller device,due to the tilting and rotation of roller device,the materials on the screen is turned on
and rolling.Qualified materials discharged by the screen of roller outer circle.Unqualified materials discharged
by the end of roller.Because the material keep on turning and rolling inside the roller, so that the material
stuck in the sieve can be ejected, can prevent clogging.
Advantage of ore separator:
1.Small power ,Low energy consumption.
2.Tube with self cleaning device, the mesh is not easy to be blocked
3.Small occupied space,Investment cost reduction.
4.Factory direct sale .Stable and reliable operation.
5.High screening efficiency,big output.
6.Easy to install, maintain, and operate.
7.Feeding mode:Artificial and mechanical drive.
Technical parameter of ore separator:
Model |
Specifications (m) |
Dip angle |
Speed (r/min) |
Screen size (mm) |
Max feeding size (mm) |
Capacity(m3/h)
|
Motor power (kw) |
|
|
Mesh size (2mm) |
Mesh size (20mm) |
|||||||
GTS820 |
Φ0.8X2 |
6° |
32 |
2-20 |
Mesh sizeX2.5 |
7 |
30 |
3 |
GTS830 |
Φ0.8X3 |
6° |
32 |
2-20 |
Mesh sizeX2.5 |
8 |
50 |
3 |
GTS1030 |
Φ1X3 |
6° |
25 |
2-20 |
Mesh sizeX2.5 |
10 |
60 |
4 |
GTS1040 |
Φ1X4 |
6° |
25 |
2-20 |
Mesh sizeX2.5 |
11 |
80 |
4 |
GTS1230 |
Φ1.2X3 |
6° |
20 |
2-20 |
Mesh sizeX2.5 |
12 |
100 |
5.5 |
GTS1240 |
Φ1.2X4 |
6° |
20 |
2-20 |
Mesh sizeX2.5 |
14 |
120 |
5.5 |
GTS1250 |
Φ1.2X5 |
6° |
20 |
2-20 |
Mesh sizeX2.5 |
15 |
140 |
5.5 |
GTS1530 |
Φ1.5X3 |
6° |
17 |
2-20 |
Mesh sizeX2.5 |
16 |
120 |
5.5 |
GTS1540 |
Φ1.5X4 |
6° |
17 |
2-20 |
Mesh sizeX2.5 |
18 |
150 |
7.5 |
GTS1550 |
Φ1.5X5 |
6° |
17 |
2-20 |
Mesh sizeX2.5 |
20 |
180 |
11 |
GTS1560 |
Φ1.5X6 |
6° |
17 |
2-20 |
Mesh sizeX2.5 |
22 |
200 |
11 |
Our service of ore separator :
1. Pre-sales service:
1). sales person, project manager, technology engineer, accountant staff.
2). professional responding team: would be very fast and exactly to send you offer.
3). choose suitable machines and make producing plan according to the raw materials, final shapes and
output capacity.
4). offer reasonable price to meet your budget.
5). invite customers to our factory, let you know how the machine work, and compare the quality with other
suppliers.
6). producing super and solid quality of machines.
7). arrange shipping and fast delivery.
8). standard export package or as your requirements.
2. After-sales service:
1). assistance to build factory.
2). repairing and maintain if any problems occur in the warranty.
3). help for installation or clerk training, if necessary, dispatch technicians to your country to install the
machines.
If you are interested in our ore separator,please contact me freely!Welcome your inquiry!
