Engineers available to service machinery overseas rotary drum screen separator

Introduction of rotary drum screen separator:

Rotary drum screen separator is used to screen stone,sandstone,coal ,charcoal ,mineral materials ,

separate big size and small size ,or one kind and another kind.and according to your raw material,

production size and mesh,our factory can make the most suitable rotary drum screen separator

according to your requirement.

Structure of rotary drum screen separator,have several parts:

1.Motor

2.Accelerator

3.Roller device

4.Frame

5.Sealing cover

6.Input and output port

Widely application of rotary drum screen separator:

1.In the stone field.for the size classification of stone,and separate the dirt and stone powder.

2.In the sandstone field,for the separate the sand and stone.

3.In the coal /charcoal industry,for the separate block and powder of coal /charcoal;washing coal

(part of coal washing machine).

4.In the chemical industry,mineral processing industry.for the size classification of blocks and powder.

Working principle of rotary drum screen separator:

Working principle of rotary drum screen separator is very simple, good understanding .Motor through

coupling connected together with accelerator and roller device,drive roller device to rotate around its axis.

when materials enter into the roller device,due to the tilting and rotation of roller device,the materials on the

screen is turned on and rolling.Qualified materials discharged by the screen of roller outer circle.Unqualified

materials discharged by the end of roller.Because the material keep on turning and rolling  inside the roller,

so that the material stuck in the sieve can be ejected, can prevent clogging.

Advantage of rotary drum screen separator:

1.Small power ,Low energy consumption.

2.Tube with self cleaning device, the mesh is not easy to be blocked

3.Small occupied space,Investment cost reduction.

4.Factory direct sale .Stable and reliable operation.

5.High screening efficiency,big output.

6.Easy to install, maintain, and operate.

7.Feeding mode:Artificial and mechanical drive.

  Technical parameter of rotary drum screen separator:
