Energy Saving Biomass Wood Pellet Mill With CE

Specifications

Energy saving biomass wood pellet mill
1.Many kinds of pellet machine
2.Small or large output
3.Burning for boiler or feeds





In some countries, the people take coal as raw materials for heating, burning for stove, burning for generating electric power. But there is SO2 and other harmful substances in the coal which had posed the threat to the environment and people health. With the improvement of living standard, people begin to care much for environment protection and healty requirements. On the other hand, the coal is the non-renewable resources. The coal in the world is fewer and fewer, and it will be exhausted sooner or later. While, the pellets, biomass materials and smokeless, can replace the coal for heating and generating the electric power, which will be the best choice for environment protection.





Introduction of biomass wood pellet mill:



1. Wood pellet mill is mainly used to make the biofuel pellets or animal pellets from wood, straw, cotton stalk, rice husk, peanut shell, bamboo, empty fruit branch, pulverized coal and waste paper, etc.

2. The final pellets are of high density, high fuel value, low moisture and low ash content.

3. Wood pellet mill is energy saving machine which can recycle and reuse the agriculture wastes to protect environment.

4. The outlet pellets can be 4-30mm size for option and the pellets can be used for fireplace, animal feed, burning for stove, etc.

5. The wood pellet mill can be used in electric industry, fertilizer industry, animal feed industry, etc.





Wood pellet mill are optional:



1. Small wood pellet mill



Model	Power	Capacity for fuel pellet	Capacity for animal feeds	Moisture	Dimension (CM)	Gross Weight (KG)
LTSP-120A	8HP Diesel engine	40-60 KG/H	40-60 KG/H	12%-20%	90*44*73	135
LTSP-120B	3KW 380V 50HZ	50-100 KG/H	100-200 KG/H	12%-20%	75*31*62	100
LTSP-150A	8HP Diesel engine	50-100 KG/H	100-200 KG/H	10%-15%	87*46*73	150
LTSP-150B	4KW 380V 50HZ	90-120 KG/H	150-220 KG/H	10%-15%	77*34*68	115
LTSP-150C	4KW 380V 50HZ	90-120 KG/H	90-120 KG/H	10%-15%	77*34*68	115
LTSP-200A	15HP Diesel engine	110-180 KG/H	220-350 KG/H	10%-15%	118*56*102	360
LTSP-200B	7.5KW 380V 50HZ	100-150 KG/H	200-300 KG/H	10%-15%	100*43*95	210
LTSP-200C	7.5KW 380V 50HZ	200-300 KG/H	200-300 KG/H	10%-15%	100*45*93	220
LTSP-200D	7.5KW 380V 50Hz	200-300 KG/H	200-400 KG/H	10%-15%	110*76*95	400
LTSP-230A	22HP	150-200 KG/H	300-400 KG/H	10%-15%	118*56*95	390
LTSP-230B	380V 50HZ 11KW	150-200 KG/H	300-400 KG/H	10%-15%	114*50*97	310
LTSP-230C	11KW 380V 50HZ	150-200 KG/H	300-400 KG/H	10%-15%	115*50*97	320
LTSP-260A	30HP	200-300 KG/H	400-600 KG/H	10%-15%	184*70*116	630
LTSP-260B	15KW 380V 50HZ	200-300 KG/H	400-600 KG/H	10%-15%	120*50*103	360
LTSP-260C	15KW 380V 50HZ	200-300 KG/H	400-600 KG/H	10%-15%	120*50*103	370
LTSP-300A	55HP	300-400 KG/H	600-800 KG/H	10%-15%	220*60*123	780
LTSP-300B	22KW 380V 50HZ	300-400 KG/H	600-800 KG/H	10%-15%	132*53*107	470
LTSP-300C	22KW 380V 50HZ	300-400 KG/H	600-800 KG/H	10%-15%	132*53*107	480



Series A:



Series B:



Series C:



2. Lantian moving roller wood pellet mill:



Model	Power	Capacity	Net/Gross Weight	Dimension
LTMP-200B	7.5 kw	80-120 kg/h	350/370 kg	1.15x0.53x1.0 m
LTMP-300B	22 kw	200-350 kg/h	575/595 kg	1.3x0.6x1.15 m
LTMP-400B	30 kw	300-450 kg/h	810/830 kg	1.4x0.7x1.6 m







3. Vertical wood pellet mill:



Model	Power	Capacity	Dimension (CM)	Weight (KG)
LTP-350	30KW	300-500 KG/H	165*70*130	1000
LTP-450	37KW	500-700 KG/H	130*70*150	1450
LTP-550	45KW	800-1000 KG/H	140*75*160	2000
LTP-800	90KW	1500-2000 KG/H	190*100*200	3900
LTP-1000	110KW	2000-3000 KG/H	210*115*205	4800



LTP-350:



4. Vertical ring-die wood pellet mill:



The new product LTRP series "double vertical ring-die pellet mill" are research, Design, Produced by ourselves, With alone shape, more reasonable structure and stability,Professional for Wood, Rice husk, Peanut shell, Bamboo and Palm fiber etc.



1) Gearbox: Continue the LTP series New generation gearbox, Driving with high-precision gears, Auto-matic Lubricant pump system keep the gearbox working stability and warranty period.
2) Vertical motor: the most characteristic is mounting hole with output shaft as the center, equidistant distribution around, More powerful and stability of machine working.
3) Blower system: Located in one side of work bin, Free control the working time,The main function is dedusting and discharge steam.
4) Working parts: Ring-die and rollers materials are alloy steel, Heat treatment made by ourselves, Hardness more than 52, In this hardness can assure the pelleting quality and warranty time,Working manner is from inside to outside press, Centrifugal force and extrusion pressure together,Produced more capacity, At the same time assure hardness and density,The special design is 4 to 8 rollers working, Increase press rate then increase capacity,Ring-die is "vertical double-deck" structure, It can use one mould with same hole size for working life increased, Moreover it can use one mould with different hole size for saving the money for another size mould.



Model	Power	Capacity	Pellet size	Weight	Dimension
LTRP-450	55 kw	0.8-1.2 ton/h	6-12 mm	2800 kg	1.4x0.75x1.55 m
LTRP-550	90 kw	1.5-2 ton/h	6-12 mm	4500 kg	1.9x0.95x1.8 m
LTRP-800	132 kw	2-3 ton/h	6-12 mm	7000 kg	2.5x1.35x2.1 m
LTRP-1000	160 kw	3-4 ton/h	6-12 mm	8500 kg	2.65x1.45x2.1 m





Pellet Production Line:





Customers's Visit:







Packaging:





The service:



1. Pre-sales service:

    1). sales person, project manager, technology engineer, accountant staff.

    2). pofessional responding team: would be very fastly and exactly to send you offer.

    3). choose suitable machines and make producing plan according to the raw materials, final shapes and output capacity.

    4). offer reasonbal price to meet your budget.

    5). invite customers to our factory, demostrate the machines, let you know how the machine work, and compare the quality with other suppliers.

    6). producing super and solid quality of machines.

    7). arrange shipping and fastly delivery.

    8). standard export package or as your requirements.

2. After-sales service:

    1). assistance to build factory.

    2). repairing and maintain if any problems occur in the warranty.

    3). help for installation or clerk training, if necessary, dispatch technicians to your country to install the machines.

    4). supply spare and wearing parts of our machines.

    5). any feedback of our wood pellet briquettes making machine can be told us, and we will try our best to support you.

    6). technology knowlogy shares with you.

    7). help for any other machine that we haven't.



The contact information:



If there is any interest in our machine, please don't hesitate to contact me.
