Specifications
non woven slitting machinepaper slitting machine
high quality
competitive price
Application:
Used to divide and cut rolls of non-woven fabrics, paper and film into bars, and then roll them into coils, especially used to cut materials of high tensility.
Features:
1) Easy to adjust the cutting width
2) Tensility can be controlled automatically with magnetic powder arrester
3) Unwind with photoelectrical edge position controller (hydraulic type)
4) Handwheel adjusts the tension unit around both sides of base materials
5) Can stop automatically with figure displaying meter and yard machine
6) The main drive gears adopt electric decelerator machine, controlling the speed by frequency conversion
7) Rewinding centre with double-friction drive
8) Unwind key air shaft and rewind leaf air shaft ensure the coiling quality of the wrap-up coil in different width
Main technical parameter:
Item |
Parameters |
||||
Max. slitting width(mm) |
900 |
1300 |
1600 |
1900 |
2300 |
Min. slitting width(mm) |
≥5 |
≥8 |
≥ 20 |
||
Max. slitting diameter(mm) |
600 |
800 |
|||
Max. rewinded diameter(mm) |
400 |
600 |
|||
Speed(m/min) |
5~120 |
||||
Power supply(KW) |
2 |
3 |
4 |
||
Dimensions (L×W×H cm) |
200×190×150 |
240×190×150 |
270×200×160 |
300×200×160 |
340×220×180 |
Weight(kg) |
1000 |
1200 |
1500 |
2000 |
2500 |
FAQ:
1.Q: Are you a factory or trading company?
A:We are a factory and manufacturer.
2.Q: Where is your factory located? How can I visit there?
A:Our factory is located in BaoShan District,Shanghai, China. You can fly to Shanghai Pudong airport directly. All our clients, from home or abroad, are warmly welcome to visit us!
3.Q: Could you send me your samples?
A: We are honored to receive your samples for Slitting or Laminating test ,then send to you back.
4.Q:How does your factory do regarding quality control?
A:"Quality is priority. YIMAI people always attach great importance to quality controlling from the very beginning to the very end.
