9t Empty Container StackerGermany KESSLER drive axle
the U.S. DANA Corporation
the Swedish VOLVO TAD 720VE engine
9t Empty Container Stacker
LG260EC8 Stacker
Machine to configure high-intensity wide-view door frame, door frame with two type,
Drive axle with heavy-duty vehicles produced in Germany KESSLER drive axle.
Transmission using the U.S. DANA Corporation TE-17000-type gearbox,
Using the Swedish VOLVO TAD 720VE engine,
Equipped with the world's most advanced variable piston pump and load-sensing valve load sensing system
Equipped with box-type chassis, frame body as the car beam welded structure, hydraulic tank and fuel tank
CAN-bus electronic control system, engine and gearbox is equipped with electronic control unit,
Equipped with an advanced user-friendly spacious cab, window glass, using large circular front corner
MODEL |
|
LG260EC8 |
Mast Height Raised (Overall Height) |
mm |
22015 |
Mast Height Lowered |
mm |
11720 |
Fork length |
mm |
|
Overall Length(With Attachments) |
mm |
6655 |
Overall Width(Without Attachments) |
mm |
4060 |
Attachment Width |
mm |
60381/12165 |
Overall Height(Overhead Guard) |
mm |
3900 |
Wheel Base |
mm |
4500 |
Front Thread |
mm |
3270 |
Rear Thread |
mm |
2330 |
Min. Turning Radius |
mm |
6000 |
Min. Intersecting Aisle |
mm |
8100 |
Overhead Guard Clearance (From face of seat) |
mm |
1200 |
Attachment Height |
mm |
2675 |
Traction Pin Height |
mm |
630 |
Rear Overhang |
mm |
960 |
Tilting Angle |
° |
2/4 |
SPECIFICATION
MODEL |
|
LG260EC8 |
Load Capacity |
kg |
9000 |
Load Center |
mm |
1220 |
Power Type |
|
Diesel |
Tire Type |
|
Pneumatic |
Lifting Speed(With Load/Without Load) |
mm/s |
630/730 |
Down Speed(With Load) |
mm/s |
600 |
Travel Speed(With Load) |
km/h |
30 |
Max. Gradeability |
% |
28 |
Wheel(Front/Rear) |
|
4/2 |
Tire(Front/Rear) |
|
14.00*24-28PR |
Wheel With Load(Front/Rear) |
kg |
41700/8800 |
Wheel Without Load(Front/Rear) |
kg |
28700/12800 |
Service Brake |
|
QIL-COOLED DISC |
Parking Brake |
|
Caliper Disc |
Engine Model |
|
VOLVO TAD 720VE |
Fuel Tank Capacity, Engine |
L |
400 |
Operation Weight |
kg |
41500 |
