Specifications
1.2WB-25 1 inch Stainless Steel Solenoid Valve2.Normally closed/open type
3.Port size:1inch
4.1 year warranty
2WB-25 1 inch Stainless Steel Solenoid Valve
Features: 2WB25 Series Stainless Steel Solenoid Water Valve
1.Port size: G1"
2.Motion pattern: Direct Action, diaphragm type
3.Working Medium: Air,Water,Oil,Gas
4.Type: Normal closed Type
5.Working Pressure: 0-1.0MPa.
6.Operating Temperature: -5-80°C
7.Voltage Range: ±10%
8.Material of valve body: Stainless steel
9.Material of seal: NPR,EPDM or VITON
How To Order:
Specification:
| Working Medium | Air,Water,Oil,Gas |
| Motion Patern | Direct Drive,Diaphragm type |
| Type | Normal Closed Type |
| Working pressure | 0~1.0MPa |
| Operation Fluid Viscosity | ≤20 CST) |
| Operating Temperature Range | -5~80°C |
| Voltage Range | ±10% |
| Material of Valve Body | Stainless Steel |
| Material of Oil Seal | NBR,EPDM or VITON |
| Model | Orifice size(mm) | CV Value | Connection Size | Working Pressure | Max.Working Pressure |
| (MPa) | (MPa) | ||||
| 2WB025-06 | 3 | 0.23 | G1/8” | 0~0.7 | 1 |
| 2WB025-08 | G1/4” | ||||
| 2WB040-10 | 4 | 0.6 | G3/8” | ||
| 2WB160-10 | 16 | 4.8 | G3/8” | Water:0~0.5 | 1.05 |
| 2WB160-15 | G1/2” | Air:0~0.7 | |||
| 2WB200-20 | 20 | 7.6 | G3/4” | Oil:0~0.5 | |
| 2WB250-25 | 25 | 12 | G1” | Gas:0~0.7 | |
| 2WB350-35 | 35 | 24 | G1-1/4” | ||
| 2WB400-40 | 40 | 29 | G1-1/2” | ||
| 2WB500-50 | 50 | 48 | G2” |
| Power consumption | AC220V | 2.0W |
| DC12V,AC110V,AC380V | 2.5W | |
| DC24V | 3.0W | |
| AC24V | 3.5W | |
| Allowable voltage range | -15%~10% | |
| IP rate | IP65 | |
| Insulation rate | Class F | |
| Action | Internally piloted | |
| Min. activate time | 0.05 s | |
| Lubrication | Needless | |
Dimensions and Sizes:
Shippment
2: We do our best to ship your order within 1 week after receiving your payment
3: We'll tell you the tracking number once your order has been sent.
Package
1:Inner packing: opp bag, then carton box for each product.
2:Outer packing: export standard carton, Foam outside protecting the goods against damage
Payment
1: We accept T/T Bank transfer, L/C, Western Union, Moneygram, Paypal.
Why choose us
1: Various style for each products and completely series pneumatic products for you to choose from.
2: Large stock for fast shipping.
3: High quality with competitive price
4: Sample order & small quantity order is ok
6: Provide free products information.
7. Reliable quality assured and active after-sell service
Feel free to contact us at anytime if you have any problems or questions on your purchase. We will resolve any problems such as damaged, not as described, missing parts, and lost items. All emails will be replied within 24 hours except Saturday. & Sunday and Chinese holidays. If you have any other requirements or questions, welcome to visit our website, or just contact with us directly. Thank you!
