5 Inch Color Digital TFT LCD Monitor

5 Inch Color Digital TFT LCD Monitor thumbnail-1
5 Inch Color Digital TFT LCD Monitor photo-1
Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Model Number:
MO-112D
Contact Supplier Request Quote Chat Now
Sharpvision Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Model Number MO-112D

Product Description



5 Inch Color Digital TFT LCD Monitor Features

  • 5 Inch TFT LCD color monitor with digital screen
  • TFT LCD monitor with wide view angle and high resolution display.
  • Picture image adjustable for Horizontal, Vertical, Mirror and Normal viewing
  • 3 languages selectable for user operation
  • Automatic backlighting for buttons.
  • Full-function remote control.
  • Multiple video formats available: AUTO/ PAL/ NTSC.
  • Up to 3 AV inputs.
  • On-board speaker.
  • Operates from 10 - 32V. Supports 12V or 24V automobile battery.
  • Automatically switches to back-up, left or right side camera views.
  • Even if it is mirror image, OSD keeps normal status.



5" Digital TFT-LCD Monitor Specifications

  • Product: 5" Digital TFT- LCD Color monitor.
  • Audio output: 1W.
  • Loudspeaker: one 4.0cm round loudspeaker.
  • Power supply: Automobile storage battery (10-32V).
  • Power consumption: about 5 W .
  • Outer dimension: 147.6mm (W) × 109mm (H) × 26.5mm (T) (without flush mount),
  • 165mm (W) × 126mm (H) × 29.2mm (T) (with flush mount).
  • Dot pitch: 0.0529(H) × 0.1587 (V).
  • Resolution: 640 x 3(RGB) x 480 .
  • Color depth:24 bit
  • Display colors:16.7M dithering.
  • Contrast: 500:1.
  • Brightness: 200cd/m2.
  • Viewing angle: U: 50 / D: 70, R/L: 70.
  • Operating temperature: -20~+70ºC,RH90%.
  • Storage temperature: -30~+80ºC,RH90%.
