Help CenterH01N2-E Rubber Insulated Welding Cable Rubber Sheathed Single Core Welding Cable of High Flexibility Grade IEC DIN
Related Products
-
H01N2-E Rubber Insulated Welding Cable 10mm 16mm 25mm 35mm2 Rubber Sheathed Single Core of High Flexibility Grade IEC DINUS$ 0.1 - 99MOQ: 100 Meters -
H01N2-D IEC DIN 100V Rubber Insulated Welding Cable 50mm 70mm 90mm 185mm 240mm2 Rubber Sheathed Single Core Welding CableUS$ 0.1 - 99MOQ: 100 Meters
-
Rubber/PVC Sheathed 16mm2 25mm2 35mm2 70mm2 95mm2 120mm2 Copper Welding Cable/Wire (YH YHF)US$ 0.1 - 33MOQ: 500 Meters
-
Metalrock Double Insulation Heavy Duty PVC Welding Cable/welding Torch Cable 50mm2 Copper/aluminum 400AMP GB5013.2-2008US$ 0.1 - 33MOQ: 500 Meters
-
Single Core 35 Sq.mm Copper Conductor Rubber Cable for Welding Machine Highly Flexible Welding CableUS$ 0.1 - 33MOQ: 500 Meters
| Temperature range: | |
| fixed installed: | -40 °C up to +80 °C |
| at usage with bending: | -25 °C up to +80 °C |
| maximal operating temp.: | +90 °C |
| at short circuit of max. 5 s: | up to 250 °C |
| Nominal voltage: | 100 V |
| Test voltage: | 1000 V |
| Maximal tensile strength: | 15 N/mm² |
| Specific el. resistance of insulation: | min. 10 MΩ x km |
| Minimal inner bending radius: | 4D |
| Behaviour in fire: | IEC 60332-1 |
| Oil resistance: | acc. to DIN VDE 0472 part 803, method A |
| Conductor: | bare or tinned copper conductor, extra fine wired stranded, class 6 acc. to IEC 60228 / HD 383 / DIN VDE 0295 |
|
| Separator: | polyester foil or paper | |
| Sheath: | rubber compound on poly-chloroprene basis (CR) (= Neoprene), i.e. EM5 acc. to DIN VDE 0282 part 803, oil resistant | |
| sheath colour: | black | |
Specifications, Size, Technical Data of H01N2-E rubber insulated welding cable Rubber sheathed single core welding cable of high flexibility grade IEC DIN
| Dimensions – number of cores x conductor cross-section | Construction of individual conductor | Conductor diameter | Sheath thickness | External diameter | Short circuit current 1s | Permitted stress | Cu weight | Cable weight | Packing * |
| nominal | nominal | nominal | min-max. | nominal | max. | approx. | |||
| N x mm² | n x mm | mm | mm | mm | kA | N | kg/km | kg/km | |
| 1 x 10 | 566 x 0,15 | 4,0 | 1,2 | 6,2 – 7,8 | 150 | 96 | 119 | CUT | |
| 1 x 16 | 903 x 0,15 | 5,1 | 1,2 | 7,3 – 9,1 | 2,37 | 240 | 153,6 | 181 | CUT |
| 1 x 25 | 1407 x 0,15 | 6,1 | 1,2 | 8,6 – 10,8 | 3,70 | 375 | 240 | 270 | CUT |
| 1 x 35 | 1974 x 0,15 | 7,6 | 1,2 | 9,8 – 12,3 | 5,18 | 525 | 336 | 363 | CUT |
| 1 x 50 | 2830 x 0,15 | 9,3 | 1,5 | 11,9 – 14,8 | 7,40 | 750 | 480 | 528 | CUT |
| 1 x 70 | 3952 x 0,15 | 11,2 | 1,5 | 13,6 – 17,0 | 10,4 | 1050 | 672 | 716 | CUT |
| 1 x 95 | 5370 x 0,15 | 12,4 | 1,8 | 15,6 – 19,5 | 14,1 | 1425 | 912 | 1012 | CUT |
| 1 x 120 | 3819 x 0,20 | 14,5 | 1,8 | 17,2 – 21,6 | 17,8 | 1800 | 1152 | 1090 | CUT |
| 1 x 150 | 4788 x 0,20 | 16,8 | 1,8 | 18,8 – 23,5 | - | 2250 | 1440 | 1305 | CUT |
| 1 x 185 | 5852 x 0,20 | 17,9 | 1,8 | 20,4 – 25,5 | - | 2775 | 1776 | 1511 | CUT |
H01N2-E rubber insulated welding cable Rubber sheathed single core welding cable of high flexibility grade IEC DIN
In Wooden drum, Iron drum, Iron wooden drum, Steel drum or according to your requirement.
Comapny Information:
Zhengzhou Hongliang Cable Co.,ltd is one of the branch of Huadong Cable Group ,and also is biggest professional import and export trade company in China.
The plant was founded in 1988, occupied 50,000 square meters,with advanced equipments of 20 sets production lines and 25 sets testing machines,Annual production capacity is more than 12 million kilometers.
Our international branch is located in Zhengzhou city,which is well-known for convenient transportation . We mainly produce and export power cable, all aluminum conductor(AAC), aluminum conductor steel reinforced(ACSR Conductor), all aluminum alloy conductor(AAAC), overhead Aerial bundled ABC cable,1-66kV power cables(including XLPE insulated cables, PVC insulated cables, SWA/STA armored cables).(XLPE/PVC insulated ABC cable),control cable, welding cable, rubber cable ,mining cables and electrical wires(PVC sheathed flexible cable). These cables can be used for power transmission in air,underground and industry,such as power station, railway, agriculture, and estate. Our products honoured I S O 9 0 0 1:2 0 0 2 and CCC,PCCC,SGS,BV certificates. We strictly according to GB,IEC,BS,ICEA, ASTM, DIN, VED, JIS standards to manufacture the products, and also we can design and produce according to customers' requirements.We have exported wires and cables to European, South America, North America, Middle East, Africa, Asia,,Oceania countries and etc.
free samples are available for further evaluation and you are highly welcome to visit our factory anytime!!
