8x3x20 AWG individual and overall shielded Instrumentation cable with served wire armor :
1.special control cable Standard
The control cable can be produced according to the standard GB9330-1988,IEC,DIN,BS,and the factory can also manufacture the cables in accordance with other standards.
2. special control cable Scope of Application
The control cable are suitable for the wiring of electrical controlling equipments and instrument,monitoring and controlling return circuit,electrical protection and measurement in power distribution unit under the circumstance that the rated voltage is up to 450/750V AC.
3. special control cable Service Conditions
(1) The long-time working temperature of conductor of PVC insulated cable is 70oC
The long-time working temperature of conductor of XLPE insulated cable is 90oC
(2) The temperature for laying the cables cannot be lower than 0oC.Permissible bending radius(r):unarmoured cable:r≥6D;(D: outer diameter of the cable);armoured or copper-tape screened cable:r≥12D;shielded flexible cable:r≥6D .
Specification |
Product Description |
2Cx22AWG |
2CX7/0.20mm OFC I.D:1.0mm PVC O.D:3.2mm PVC |
4Cx22AWG |
4CX7/0.20mm OFC I.D:1.0mm PVC O.D:3.8mm PVC |
6Cx22AWG |
6CX7/0.20mm OFC I.D:1.0mm PVC O.D:4.1mm PVC |
8Cx22AWG |
8CX7/0.20mm OFC I.D:1.0mm PVC O.D:4.5mm PVC |
10Cx22AWG |
10CX7/0.20mm OFC I.D:1.0mm PVC O.D:5.0mm PVC |
12Cx22AWG |
12CX7/0.20mm OFC I.D:1.0mm PVC O.D:5.5mm PVC |
2Cx22AWG |
2CX7/0.20mm OFC I.D:1.0mm PVC + AL O.D:3.2mm PVC |
4Cx22AWG |
4CX7/0.20mm OFC I.D:1.0mm PVC + AL O.D:3.8mm PVC |
6Cx22AWG |
6CX7/0.20mm OFC I.D:1.0mm PVC + AL O.D:4.1mm PVC |
8Cx22AWG |
8CX7/0.20mm OFC I.D:1.0mm PVC + AL O.D:4.5mm PVC |
10Cx22AWG |
10CX7/0.20mm OFC I.D:1.0mm PVC + AL O.D:5.0mm PVC |
12Cx22AWG |
12CX7/0.20mm OFC I.D:1.0mm PVC + AL O.D:5.5mm PVC |
2Cx22AWG |
2CX7/0.20mm OFC I.D:1.0mm PVC+AL+7/0.20mm OFC GroundO.D:3.2mm PVC |
4Cx22AWG |
4CX7/0.20mmOFC I.D:1.0mm PVC+AL+7/0.20mm OFC Ground O.D:3.8mm PVC |
6Cx22AWG |
6CX7/0.20mmOFC I.D:1.0mm PVC+AL+7/0.20mm OFC GroundO.D:4.1mm PVC |
8Cx22AWG |
8CX7/0.20mmOFC I.D:1.0mm PVC+AL+7/0.20mm OFC GroundO.D:4.5mm PVC |
10Cx22AWG |
10CX7/0.20mmOFC I.D:1.0mm PVC+AL+7/0.20mm OFC GroundO.D:5.0mm PVC |
12Cx22AWG |
12CX7/0.20mmOFC I.D:1.0mm PVC+AL+7/0.20mm OFC GroundO.D:5.5mm PVC |
8x3x20 AWG individual and overall shielded Instrumentation cable with served wire armor
1.Packing Lengths: 100m/roll, 200m/roll, 305m/roll. Other lengths available according to client's Request.
2. Inner packing: Wooden reel, plastic reel.
3. Outer packing: Carton box, pull box, pallet.
4. Other packing available according to client's Request.
Zhengzhou Hongliang Cable Co.,ltd is one of the branch of Huadong Cable Group ,and also is biggest professional import and export trade company in China.
The plant was founded in 1998, occupied 50,000 square meters,with advanced equipments of 20 sets production lines and 25 sets testing machines,Annual production capacity is more than 12 million kilometers.
Our international branch is located in Zhengzhou city,which is well-known for convenient transportation . We mainly produce and export power cable, all aluminum conductor(AAC), aluminum conductor steel reinforced(ACSR Conductor), all aluminum alloy conductor(AAAC), overhead Aerial bundled ABC cable,1-66kV power cables(including XLPE insulated cables, PVC insulated cables, SWA/STA armored cables).(XLPE/PVC insulated ABC cable),control cable, welding cable, rubber cable ,mining cables and electrical wires(PVC sheathed flexible cable). These cables can be used for power transmission in air,underground and industry,such as power station, railway, agriculture, and estate. Our products honoured I S O 9 0 0 1:2 0 0 2 and CCC,PCCC,SGS,BV certificates. We strictly according to GB,IEC,BS,ICEA, ASTM, DIN, VED, JIS standards to manufacture the products, and also we can design and produce according to customers' requirements.We have exported wires and cables to European, South America, North America, Middle East, Africa, Asia,,Oceania countries and etc.
1.Quality is our culture. we are one of the most famous brand in China. Quality is verified by clients.
2. High-effiency oversale team makes your business much easier.
3. free samples are available for further evaluation and you are highly welcome to visit our factory anytime!
1.what is our payment term ?
Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight.
2.what is the lead time ?
The lead time usually is 10 - 30 working days.
3.what is the package of the cable ?
The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.
4.Could we provide the free sample for customer ?
Sure, we provide the free sample for customer to checking.
