Help CenterCopper Clad Aluminum With Polyester Coating
Related Products
Specifications
Feature:High thermal endurance,Good chemical properties,Good mechanical & electrical properties High thermal shock,High adhesive
1.PERFOMANCE:
The enameled copper clad aluminum wire has excellent flexibility,scratch resistance,adhesion,electrical properties and solvent resistance properties.
2.Detailed Product Description:
Product: Enameled CCA
Enameled aluminum wire(EAL)
Enameled copper wire(ECU)
Copper clad aluminum wire(CCA)
Diameter: Enameled copper clad aluminum wire(ECCA):012-0.90mm
Enameled aluminum wire(EAL):0.13-2.5mm
Enameled copper wire:0.10-2.0mm
Copper clad aluminum wire(CCA):0.12-2.5mm
Copper pertage in weight is 30%-40%
Insulation material: Polyester,Polyurethane,Polyester-imide
Model:QA(PEW),QZ(UEW)and QZY
Class:130/155/180
Insulation Tickness: 0.007-0.0090mm
Core number:one
Shape materialsRound
Conductor:0.003
Elongation:5%-10%
Tensile strength:172Mpa
Paint:1736s
Paint coating(mm):0.010--0.060
Packing:Carton
3.Application:
Widely use of the various kinds of electrical,electronics,instrumentation,telecommunications equipment.Such as
Electrical tool, Auto-motor and tranfomers,Electronic compoments,Instrument windings,Step motors,Communication equipment, Small-sized motors.
cable,ballast,house application and so on.
