Outdoor Vhf 88-108MHz Directional Yagi Antenna

Name: Outdoor Vhf 88-108MHz Directional Yagi Antenna
Brand: AMEISON
SKU: 126223545
Availability: InStock

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

AMEISON

Model Number:

AMXY-88108-6

Shenzhen Ameison Communication Equipment Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or HongKong

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name AMEISON

Model Number AMXY-88108-6

88-108MHz Directional Yagi Antenna

vhf yagi antenna

Feature:

High gain

Aluminum alloy framework

Full day working

Optimized dimension

Mounting way can be Vertical or Horizontal

Application:

88-108MHz system

FM radio air defense warning system

Point-to-point,point-to-multipoint system

Wireless bridging,client termination antenna

AMXY-88108-6 Electrical Specifications
Frequency range(MHz)	88-108
Bandwidth(MHz)	20
Gain(dBi)	6
Element	3
Half-power beam width(°)	H:42 V:38
Front-to-back ratio(dB)	≥16
VSWR	≤1.5
Input Impedance(Ω)	50
Polarization	Horizontal
Maximum input power(W)	100
Lightning protection	DC Ground
Input connector type	F male or others
Mechanical Specifications
Dimensions(mm)	1920150080
Cable length(m)	0.3
Antenna weight(kg)	0.9
Operating temperature(°c)	-40~60
Rated Wind Velocity(m/s)	60
Clamp	U-shape
Mounting hardware(mm)	35~50
