AMEISON 11 DBi 9 Elements 650-850 MHz Directional Yagi Antenna 700MHz Antenna Yagi 4g Lte

Name: AMEISON 11 DBi 9 Elements 650-850 MHz Directional Yagi Antenna 700MHz Antenna Yagi 4g Lte
Brand: AMEISON
SKU: 126223479

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

AMEISON

Model Number:

AMXY-6585-11

Shenzhen Ameison Communication Equipment Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or HongKong

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name AMEISON

Model Number AMXY-6585-11

AMEISON 11 dBi 9 Elements 650-850 MHz Directional Yagi Antenna 700MHz antenna yagi 4g lte

Model No.: AMXY-6585-11

Features:

Superior performance

All weather operation

Solid aluminium elements

Heavy-duty aluminium boom

Mounting way can be Vertical or Horizontal

Application:

650-850MHz system

Digital Mobile TV System

Client terminationantenna

AMXY-6585-11 Electrical Specifications
Frequency range(MHz)	650-850
Bandwidth(MHz)	200
Gain(dBi)	11
Element	9
Half-power beam width(°)	H:38 V:32
Front-to-back ratio(dB)	≥16
VSWR	≤2.0
Input Impedance(Ω)	75
Polarization	Horizontal
Maximum input power(W)	100
Lightning protection	DC Ground
Input connector type	F Female or others
Mechanical Specifications
Dimensions(mm)	100026554
Cable length(m)	0.3
Antenna weight(kg)	0.51
Operating temperature(°c)	-40~60
Rated Wind Velocity(m/s)	60
Mounting Hardware	U-Bolts For Pole Mounting
Mounting hardware(mm)	Φ35~Φ50
