1710 - 2170 MHz Directional Yagi Antenna
AMXY-1722-15
Feature:
High gain
Heavy-duty Anodized Aluminum alloy framework
Full day working
Optimized dimension
Vertical or Horizontal
Application:
3g system
Point-to-point, point-to-multipoint system
Wireless bridging, client terminal antennas
|
AMXY-1722-15 Electrical Specifications | |
Frequency range(MHz) |
1710-2170 |
Bandwidth(MHz) |
460 |
Gain(dBi) |
15 |
Element(s) |
16 |
Half-power beam width(°) |
H:35 V:30 |
Front-to-back ratio(dB) |
≥16 |
V.S.W.R. |
≤1.8 |
Input Impedance(Ω) |
50 |
Polarization |
Horizontal or Vertical |
Maximum input power(W) |
100 |
Lightning protection |
DC Ground |
Input connector type |
N-Female or Requested |
Mechanical Specifications | |
Dimensions(mm) |
710*110*44 |
Cable length(m) |
0.3 |
Antenna weight(kg) |
0.4 |
Operating temperature(°c) |
-40~60 |
Rated Wind Velocity(m/s) |
60 |
Clamp |
U-shape |
Mounting hardware(mm) |
Φ35~Φ50 |
High-Tech Enterprise In ShenZhen
Have Own Import-Export Qualification Rights
License Number: 01634441
Shenzhen Ameison Antennas Co.,Ltd. established in 2009, Ameison manufactures
a wide variety of OEM and ODM antennas including: LTE, WIMAX, Wi-Fi, 3G, 4G,
DECT, WLAN, CDMA, GPRS,CMMB, DMB, GSM and DVB-T types etc.
(our products arrange cover the frequency from 88 MHz to 5.85 GHz.)
We are a manufacturer, NOT trading company.
High-quality! Made In Shenzhen of China! Global Sharing!
To be a business partner with us now!
OEM and ODM orders are warm welcome.
More items want to know, please do not hesitate to visit our company website or email to request
the catalogue to beavailable.
