5.8GHz 5dBi High Performance desktop Wifi Rubber Duck ZTE Modem External Antenna
Specifications
Used in UNII, ISM, IEEE 802.11a, Radio Local Area Networks (RLAN), Fixed Wireless Access Systems (FWA), WiMAX and MESH networks.
It is a coaxial sleeve design with an omni-directional pattern
Better performance than most stock AP antennas
Tilt and swivel design
It is ideally suited for 5.8GHz ISM band applications as well as cellular applications
This flexible antenna features a tilt-and-swivel SMA-Male connector, allowing them to be used vertically, at a right angle, or any angle in-between.
Feature:
Good appearance
Durable, corrosion resistance
Full day for working
Optimized dimension
High Gain, Lower VSWR,Strongly Anti-interference
Application:
5.8GHz UNII/ISM frequency range
5.8GHz WLAN System
Multipoint transmission
|
AMXT-5800-5 Electrical Specifications | |
Frequency rang-MHz |
5725-5850 |
Bandwidth -MHz |
125 |
Gain -dBi |
5 |
Beam width -° |
H:360 V:65 |
VSWR |
≤1.5 |
Input Impedance-Ω |
50 |
Polarization |
Vertical |
Max power -W |
50 |
Lightning protection |
DC ground |
Connector model |
SMA Male or others |
Mechanical Specification | |
Size -mm |
197 |
Antenna weight-kg |
0.02 |
Working Temperature -°c |
-40~60 |
Radome color |
Black |
Ameison Antennas Factory delivers high quality antennas and solutions for the global defence, security and communications markets.
We manufacture low cost antennas for wireless networking and cellular end-user antenna applications, RFID and Defence.
your choice + our products > win-win situation
We are a manufacturer, NOT trading company.
Ameison Antennas Factory is one of leading professional antenna manufacturers and only one has our own Antennas Far Field Automatic Measurement System in Shenzhen.
Your Reliable Antennas Partner in China
Tel:+86-755-8991 4346(20 lines)
Fax:+86-755-8991 4746
Factory Address: 33-2#, Fajiafu Industrial Zone, Shantangwei, Pingdi, Longgang, Shenzhen, 518117, P.R.China.
China Plant: Shenzhen Ameison Communication Equipment Co.,Ltd.
Hong Kong Head Office: FOXTENNA COMMUNICATION LIMITED.
For question most asked vist our company Official Website:
After-sale service:
1)All of our product will have been strictly test before packing
2)All of our product will be well packed before shipping
3)All of our prodect will have one year quality warranty, free maintenance with warranty period!
OEM/ODM ORDERS ARE WELCOMED BY US.
