Help CenterAMEISON 806 - 2500 MHz 3dBi Omni-directional DAS Ceiling Mount Dome 2.4ghz Indoor Ceiling Mount Wifi Antenna
Related Products
-
6dBi 902-928 MHz RFID Omnidirectional Fiberglass Dipole Antenna Gsm Repeater AntennaNegotiableMOQ: 100 Pieces -
AMEISON 420-480MHz Outdoor Omni-directional Fiberglass 5 DBi 477 Mhz Radio AntennaNegotiableMOQ: 100 Pieces
-
AMEISON 1920 - 2170 MHz Omni-directional Fiberglass 10 DBi 3g Outdoor Collapsible AntennaNegotiableMOQ: 100 Pieces
-
AMEISON 806-960 / 1710-2500 MHz 5 DBi Omni-directional DAS Gsm Wifi 3g Quad Band AntennaNegotiableMOQ: 100 Pieces
-
AMEISON 144 - 165 MHz Omni-directional Fiberglass 5 DBi Collinear Vhf AntennaNegotiableMOQ: 100 Pieces
AMXCN-8025-3
Feature:
Exquisite appearance
Suitable for ordinary ceiling mounting
Optimized dimension
Wide frequency band, low standing wave, strong anti-interference ability
Application:
Indoor omni-directional coverage
GSM/CDMA/PCS/3G/WLAN system
|
AMXCN-8025-3 Electrical Specifications | ||
Frequency range(MHz) |
806~960 |
1710-2500 |
30°(dBi)radiation angle gain |
NA |
≤-6 |
85°(dBi)radiation angle gain |
≥1.5 |
≥2 |
V Side(dBi)Gain |
≥1.5 |
≥3.0 |
85º(dB)radiation angle directional diagram roundness |
≤1.0 |
|
V.S.W.R. |
≤1.5 |
|
Input Impedance(Ω) |
50 |
|
Polarization |
Vertical |
|
Third-order Intercept Point(dBm@2×33dBm) |
≤-107 |
|
Maximum input power(W) |
50 |
|
Lightning protection |
DC Ground |
|
Input connector type |
N Female |
|
Mechanical Specifications | ||
Antenna Dimensions (mm) |
Φ208*118 |
|
Antenna weight(kg) |
0.3 |
|
Operating temperature(°c) |
-40~60 |
|
Radome material |
ABS |
|
Radome color |
white |
|
Mounting way |
fastened with screw nuts |
|
