11dbi 1.2ghz antenna 1100 - 1300 MHz Omnidirectional Fiberglass Antenna security camera wireless antenna
AMXF-1200-11
Feature:
Exquisite appearance
Good impact resistance, waterproofing and anticorrosion ability
Full day working
Optimized dimension
High gain, low standing wave, strong anti-interference ability
Application:
1.2 GHz system Wireless communication and datatransmission system
|
AMXF-1200-11 Electrical Specifications | |
Frequency range(MHz) |
1100-1300 |
Bandwidth(MHz) |
200 |
Gain(dBi) |
11 |
Half-power beam width(°) |
H:360 V:9 |
VSWR |
≤1.5 |
Input Impedance(Ω) |
50 |
Polarization |
Vertical, Linear |
Maximum input power(W) |
100 |
Lightning protection |
DC Ground |
Input connector type |
N Female or Requested |
Mechanical Specifications | |
Dimensions (mm) |
Φ20*1350 |
Antenna weight(kg) |
0.82 |
Operating temperature(°c) |
-40~60 |
Rated Wind Velocity(m/s) |
60 |
Radome color |
Gray or White or others |
Radome Material |
Fiberglass |
Waterproof Standard |
IP65/ IP67 |
Mounting way |
Wall/ Pole-holding |
Mounting hardware(mm) |
35 - 50 |
1) All of our products do strictly 100% inspection and follow AQL standard before packing;
2) All of our products are well packed before shipping;
3) All of our prodects have one year quality warranty, free maintenance within warranty period!
Ameison promises all our issued products pictures on the internet are shot by our professional photographers, and these are real existence, NO duplication/ stolen figures/ infringement of intellectual property rights/ PS technical means etc.
The ownership of pictures and tests are owned by Ameison, if without permission and usurp unauthorized, Ameison will pursue legal liabilities according to laws and regulations and ask for economic compensation.
Due to there appears technical data is unreal even fake on the market, Ameison always sticks to the facts but not tell stories, all our technical specifications are real and tested by ourselves, welcome to request our related test reports and samples for compared and distinguishing the true from the false.
Genuine Quality Assured
It’s Your Excellent Choice High Quality Products.
Ameison is TOP3 professional communication and wireless antennas industry manufacturer enterprise in Shenzhen, we hope to establish long-term business relationship with you.
More items want to know, please visit our official company website to request the catalogue; we warmly welcome you to schedule a visit to our factory anytime.
