AMEISON 806-960/1710-2690/1710-2690MHz 4dBi Dual Band Dual Polarized DAS MIMO Omni indoor dc ceiling antenna
806-2690MHz Omni directional Ceiling Mount Antenna
AMXC-8027V2H1-4
Feature:
Exquisite appearance
Suitable for ceiling mounting
Optimized dimension
Vertical and Horizontal
Application:
Indoor omni directional coverage
GSM/CDMA/PCS/3G/WLAN/4G LTE system
|
AMXC-8027V2H1-4 Electrical Specifications | ||
Interface |
Vertical |
Horizontal |
Frequency range(MHz) |
806~960/1710~2690 |
1710~2690 |
Gain(dBi) |
2 / 3 |
4 |
Half-power beam width(°) |
H:360 V:90/60 |
H:360 V:55 |
V.S.W.R. |
≤1.5 |
≤1.5 |
Third-order Intercept Point(dBm) |
≤-107 |
|
Isolation between ports (dB) |
≥25 |
|
Cross-polar ratio(dB) |
≥15@0º ≥10@+/-60º |
|
Input Impedance(Ω) |
50 |
|
Polarization |
Vertical and Horizontal |
|
Maximum input power(W) |
50 |
|
Lightning protection |
DC Ground |
|
Input connector type |
2xN Female |
|
Mechanical Specifications | ||
Dimensions(mm) |
Φ185*82 |
|
Antenna weight(kg) |
0.35 |
|
Operating temperature(°c) |
-40~60 |
|
Radome material |
ABS |
|
Radome color |
white |
|
Mounting way |
Screw down nut |
|
Dual Polarized Design (Vertical and Horizontal polarization)
This antenna features an unique array of cross dipole elements.
The antenna is fed via two N-Female ports, one for vertically polarized and one for horizontally polarized signals.
These feature makes these antennas ideal for polarization diversity systems.
This is a high performance ceiling mount antenna specifically designed for DAS (Distributed Antenna Systems) which are used to distribute Cellular and WiFi signals throughout a building or area.
The Multi-Band design of this antenna eliminates the need to purchase different antennas for each frequency.
This simplifies installations since the same antenna can be used for a wide array of in-building wireless applications where wide coverage is desired.
The aesthetically pleasing design of this antenna makes it ideal for use in almost any indoor environment.
It can be easily mounted through a single 11/16" hole in a solid or suspended ceiling up to 1" thick.
This antenna features a 12 inch coax lead terminated with an N-Female connector.
Special order connectors are also available.
