Specifications
These 3.5 GHz antennas are well suited for the following applications: IEEE 802.16e, WiMAX, Mobile WiMAX and SOFDMA.Antenna Manufacturer 3400-3600MHz(3.5GHz) 12dBi Wimax CPE Fiberglass antenna omnidirectional
These 3.5 GHz antennas are well suited for the following applications: IEEE 802.16e, WiMAX, Mobile WiMAX and SOFDMA.
This is an economical yet high performance omni-directional WiFi antenna designed and optimized for the 3.5GHz band.
Typical applications include IEEE 802.16e, WiMAX and Mobile WiMAX applications. This antenna is ideally suited for multipoint applications where wide coverage is desired.
Features:
Superior Performance
All weather operation
Integral N-Female Connector
Supplied with mast mounting kit
RoHS Compliant
Applications:
3.5 GHz Band Applications
Mobile WiMAX, SOFDMA, Multipoint Applications
Wireless LAN systems
IEEE 802.16e Applications
WiMAX
|
AMXF-3500-12 Electrical Specifications | |
Frequency range(MHz) |
3400~3600 |
Bandwidth(MHz) |
200 |
Gain(dBi) |
12 |
Half-power beam width(°) |
H:360 V:6 |
VSWR |
≤1.5 |
Input Impedance(Ω) |
50 |
Polarization |
Vertical |
Maximum input power(W) |
100 |
Lightning protection |
DC Ground |
Input connector type |
N Female or Requested |
Mechanical Specifications | |
Dimensions (mm) |
Φ20*830 |
Antenna weight(kg) |
0.4 |
Operating temperature(°c) |
-40~60 |
Rated Wind Velocity(m/s) |
60 |
Radome color |
Gray |
Mounting way |
Pole-holding |
Mounting hardware(mm) |
35 - 50 |
