1420 – 1530 MHz Directional Base Station Repeater Sector Panel Antenna
AMXP-1415S-D14L65X
Feature:
High gain
Full day working
Optimized dimension
Dual polarization
Application:
1420 - 1530 MHz Wireless communication and data transmission system
|
AMXP-1415S-D14L65X Electrical Specifications | |
Frequency range |
1420~1530 |
Polarization |
±45º |
Gain(dBi) |
14 |
half-power beam width(0°) |
H:65 V:14 |
Front-to-back ratio(dB) |
≥25 |
Input Impedance(Ω) |
50 |
Isolation between ports |
≥28dB |
Cross-polar ratio |
≥15dB@0º ≥10dB@+/-60º |
Sidelobe suppression for first sidelobe above horizon |
15 dB |
VSWR |
≤1.5 |
Maximum input power(W) |
200 |
Lightning protection |
DC Ground |
Mechanical Specifications | |
Input connector type |
4-7/16 DIN Female |
Dimensions-mm (Height/Width/Depth) |
800*280*80 |
Packing size(mm) |
850*320*160 |
Antenna weight (kg) |
6.3 |
Radome material |
UPVC |
Radome color |
Gray |
Mechanical tilt(°) |
0~10 |
Operating temperature(°c) |
-40~60 |
Rated Wind Velocity(m/s) |
60 |
Waterproof Standard |
IP67 |
Mounting way |
pole-holding |
Mounting hardware(mm) |
35~90 |
