5725 – 5850 MHz Directional Base Station Repeater Sector Panel Antenna
AMXP-5800V-D17L90
Feature:
High gain
Full day working
Optimized dimension
Vertical or horizontal
Application:
5.8 GHz WLAN system
5.8 GHz ISM band
Public wireless hot spot coverage
AMXP-5800V-D17L90 Electrical Specifications | |
Frequency range(MHz) | 5725~5850 |
Polarization | Vertical |
Gain(dBi) | 16.5 |
Half-power beam width(°) | H:90 V:7 |
Front-to-back ratio(dB) | ≥23 |
Input Impedance(Ω) | 50 |
VSWR | ≤1.5 |
Sidelobe suppression for first sidelobe above horizon | 15 dB |
Maximum input power(W) | 200 |
Lightning protection | DC Ground |
Mechanical Specifications | |
Input connector type | N Female |
Dimensions-mm (Height/Width/Depth) | 580*114*54 |
Packing size(mm) | 620*155*145 |
Antenna weight (kg) | 3.0 |
Radome material | UPVC |
Radome color | Gray |
Mechanical tilt(°) | 0~10 |
Operating temperature:(°c) | -40~60 |
Rated Wind Velocity(m/s) | 60 |
Waterproof Standard | IP67 |
Mounting way | pole-holding |
Mounting hardware(mm) | 35~75 |
